Model V3-101-0 V-Series® Hand Cutting Tip

Description

Model V3-101 is a single-piece acetylene tip for hand cutting torches.

Model V3-101-0 V-Series® general preheat single-piece hand cutting tip for use with acetylene

Model V3-101 is a single-piece acetylene tip for hand cutting torches.

Single-piece copper hand cutting tip

General preheat

For use with acetylene

Cuts relatively clean steel

Compatible with V-Series® torches

Typical applications include construction, maintenance, metal art, etc.

Marked with model number and tip size for easy identification

Model V3-101-0 V-Series® Hand Cutting Tip

1 Year

V3-101-0

Harris

Acetylene

Acetylene PSIG (Min. – Max.): 7

Compatible Cutting Attachment Model Number: V-1350;VH13

Compatible Handle Model Number: V-100C-2;VH10

Construction: One piece – Copper

Cutting Depth: 5/16 in. – 5/8 in. (7.9mm – 15.9mm)

Cutting Drill Size: No. 61

Gas / Gas Service: Acetylene

Oxygen PSIG (Min. – Max.): 30 – 40

Preheat Type: General

Recommended Items/Accessories: Standard One-Piece Tip Cleaner – Model C-9 – PN 9000156

Style: Hand cutting

Tip Size / Number: 0

Typical Application: Maintenance;Metal art;Construction

What’s Included: Model V3-101-0 V-Series® Hand Cutting Tip

Model Name: V3-101-0
