Model 25GX-145-540 Medium-to-Heavy Duty Single-Stage Pressure Regulator

Description

Model 25GX single-stage regulator is designed to be the next generation workhorse of the Harris industrial line. It features large, easy-to-read gauges and an ergonomic adjusting knob that also shields the adjusting mechanism from contaminants. Conveniently packaged in clamshell for point-of-purchase display.

Model 25GX-145-540 best value medium-to-heavy duty single-stage regulator (Clamshell)

Model 25GX single-stage regulator is designed to be the next generation workhorse of the Harris industrial line. It features large, easy-to-read gauges and an ergonomic adjusting knob that also shields the adjusting mechanism from contaminants. Conveniently packaged in clamshell for point-of-purchase display.

High end features for economical price

Workhorse of Harris industrial regulator line

Ergonomic ABS plastic knob for easy grip and precise adjustment

Brass body and electroless nickel-plated brass bonnet for longer service life

Neoprene diaphragm for improved pressure control

2.5 in. Steel dual scale easy-to-read gauges

One-piece encapsulated seat design with internal filter to protect the PTFE Teflon® seat from particulate contamination

UL® listed

Conveniently packaged in clamshell for point-of-purchase display

Model 25GX-145-540 Medium-to-Heavy duty Single-Stage Pressure Regulator

7 Years

Oxygen-25GX-145PSI-CGA540

Harris

UL

Oxygen

Adjusting Knob: ABS plastic

Body: Brass

Bonnet: Electroless nickel-plated zinc

Certification: CGA E-4;UL® listed

Cv: 0.17

Delivery Pressure Gauge (PSIG): 200

Delivery Pressure Range (PSIG): 0 – 145

Diaphragm: Neoprene

Duty: Medium to heavy

Gas / Gas Service: Oxygen

Gauges: 2.5 in. Steel dual scale

Inlet Connection: CGA 540

Maximum Inlet Pressure (PSIG): 3000

Nozzle: Brass

Outlet Connection: 9/16 in. – 18 LH

Pressure Regulation PSIG/100 PSIG: 0.2

Recommended Items/Accessories: Steel Gauge Guard – Red (Fuel) – PN 4300238;Steel Gauge Guard – Green (Oxygen) – PN 4300239

Seat: PTFE Teflon®

Supply Pressure Gauge (PSIG): 4000

What’s Included: Model 25GX-145-540 Medium-to-Heavy duty Single-Stage Pressure Regulator

Model Name: Oxygen-25GX-145PSI-CGA540
