Description
Yale LBDY8840FL 626 Storeroom Mortise Lock Body
Yale LBDY8840FL 626 Storeroom Mortise Lock Body delivers exceptional strength and durability tailored for commercial environments. This Grade 1 lever mortise lock features a storeroom function with a deadbolt, ensuring heightened security for your premises. Its satin chrome finish not only enhances aesthetic appeal but also ensures longevity against wear and tear. Designed for ease of installation, the Yale 8800 Series boasts quick lever handing, a field-reversible latchbolt, and a standard nonhanded strike. The reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim provide an extra layer of protection, earning an ANSI/BHMA Grade 1 certification for operational excellence. This lock supports a backset of 2-3/4″ and accommodates door thicknesses ranging from 1-3/4″ to 3-1/4″ (to order). The latchbolt features a robust 3/4″ stainless steel throw, while the cylinder is a 6-pin, keyed-random brass option supplied with two keys. The Yale LBDY8840FL is UL/cUL fire-rated for up to 3 hours, ensuring compliance with safety standards. With its versatile finishes available in 17 options and a 10-year mechanical warranty, the Yale LBDY8840FL is a reliable choice for any commercial door hardware needs.
Storeroom Mortise Lock Body
Grade 1 Lever Mortise Lock Body, Storeroom with Deadbolt Function, Satin Chrome Finish
Yale 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
Lock installation is easy with quick lever handing, field reversible latchbolt and standard nonhanded strike.
The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
- ANSI/BHMA:Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL-cUL:UL/cUL fire rated up to 3 hours
- Windstorm:Certified (refer to local codes)
- Mechanism:Stainless steel
- Backset:2-3/4″
- Latchbolt:3/4″ stainless steel throw
- Door Thickness:1-3/4″ standard, to 3-1/4″ thick doors to order
- Fronts:Bevel front, free-floating to adjust from flat to standard bevel of 1/8″ in 2″
- Cylinders:Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
- Reversibility:Field reversible handing
- Strikes:1-1/4″ curved lip for 1-3/4″ door standard; other lip lengths to special order; all reversible
- Finishes:Available in 17 finishes
- Warranty:10 year mechanical
Attributes
Commercial Residential: Commercial
Finish: 626/US26D
Finish Family: Matte Silver
Function: 40-Storeroom Deadbolt
Grade: Grade 1
Installation: Commercial
Pack Qty: 1
Series: Yale 8800 Series Mortise Locks
Subtype: Lock Bodies
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
