Description
Yale AU4701LN 626 Grade 1 Passage Latch
Yale AU4701LN 626 Grade 1 Passage Latch combines durability and functionality, making it an ideal choice for a wide array of commercial applications. This Grade 1 cylindrical lock features the elegant Augusta lever design in a sleek satin chrome finish, ensuring aesthetic appeal while providing reliable security. The non-handed design simplifies installation, allowing for versatile use across various door configurations. Certified to ANSI/BHMA Grade 1 standards, the AU4701LN ensures top-tier quality, while the UL Fire Listing for all functions provides peace of mind regarding safety. With a backset of 2-3/4 inches and compatibility with door thicknesses ranging from 1-3/4 inches to 2 inches, this latch accommodates a range of door types. The lock features a bolt projection of 1/2 inch, with a latch bore diameter of 1 inch, making it easy to install in standard door preparations. The lock face measures 1-1/8 inches by 2-1/4 inches, and it is equipped with an ANSI strike. With a 5-year limited warranty, the Yale AU4701LN offers both quality and longevity, ensuring it meets the demands of busy commercial environments. Upgrade your door hardware with this dependable and stylish passage latch from Yale.
Grade 1 Passage Latch
Grade 1 Passage/Closet Latch Cylindrical Lock, Augusta Lever, Non-Keyed, Satin Chrome Finish, Non-Handed
Yale 4700LN cylindrical locks are the idea choice for a wide variety of commercial applications where consistent quality, ease of use and installation are required at an economical price. The 4700LN Series is certified to ANSI/BHMA Grade 1 standards and is UL Fire Listed for all functions insuring reliability and peace of mind.
Your choice of a wide variety of commercial applications.
Ideal choice for a wide variety of grade 1 commercial applications where consistent quality, ease of use and installation are required at an economical price.
- Door Thickness: 1-3/4″ (44mm) to 2″ (51mm); 1-3/8″ (35mm) or 2-1/4″ (57mm), please specify on order
- Strike: ANSI 4-7/8″ x 1-1/4″ x 1-1/4″ (124mm x 32mm x 32mm) lip to center.
- Backset: 2-3/4″ (70mm)
- Handing: Non-handed
- Installation: ANSI/BHMA A156.115(-W)
- ANSI/BHMA: Certified ANSI/BHMA A156.2, Series 4000 Grade 1
- Warranty: 5 year
Attributes
Ansi: ANSI A156.2, Series 4000, Grade 1
Ansi Function: F75
Base Material: Brass, Bronze
Bolt Projection: 1/2″
Bore Hole Diameter: 2-1/8″
Box Depth Fraction: 7-1/4″
Box Height Fraction: 3-3/4″
Box Width Fraction: 6-3/4″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: Non-Keyed
Cylinders Present: Non-Keyed
Door Thickness: 1-3/4″ to 2″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 01-Passage/Closet Latch
Function Family: Passage
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Latch Bore Diameter: 1″
Lever Knob: Lever
Lever Knob Design Name: Augusta
Leverknob Design: AU – Augusta Lever
Leverknob Design Family: Straight Return Lever
Limited Warranty: 5 Years
Lock Face Size: 1-1/8″ x 2-1/4″
Manufacturer Function: Passage/Closet Latch
Maximum Door Thickness: 2″
Minimum Door Thickness: 1-3/4″
Origin: United States
Pack Height: 3.75″
Pack Length: 7.25″
Pack Qty: 1
Pack Volume: 183.52 in³
Pack Width: 6.75″
Product Height: 3.75″
Product Length: 7.25″
Product Width: 6.75″
Projection: 3-1/2″
Rose Escutcheon: Rose
Roseescutcheon Design: 3-1/2″ Rose Diameter
Roseescutcheon Dimensions: 3-1/2″
Screws: Combination
Series: 4700LN Grade 1 Cylindrical Lever Locks
Ship Weight: 4 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 693
Std Latch Type: Beveled Spring Latch (Unguarded)
Std Strike Height: 4-7/8″
Std Strike Number: 497
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4″
Strike Dimensions: 1-1/4″ x 4-7/8″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Resources
- 4700LN Grade 1 Cylindrical Lever Locks Cut Sheet
- 4700LN Series – Grade 1 Cylindrical Locks Catalog
- 4700N Series Installation Instructions
- 5300LN Grade 2 or 4700LN Grade 1 Cylindrical Lever Locks Installation Instructions
- Electrified Wiring Instructions 5390LN/5391LN and 4790LN/4791LN
