Yale MO4704LN 626 Grade 1 Entry Lock Instructions
Yale MO4704LN 626 Grade 1 Entry Lock offers a robust solution for various commercial applications, combining exceptional durability with ease of use. This Grade 1 cylindrical lock features the elegant Monroe lever design and is equipped with a conventional cylinder utilizing a PARA keyway. The satin chrome finish not only enhances its aesthetic appeal but also provides lasting protection against wear. Certified to ANSI/BHMA Grade 1 standards, the Yale 4700LN series ensures reliability and performance in demanding environments, making it an ideal choice for high-traffic areas. The lock is UL Fire Listed, offering an added layer of safety with a fire rating of up to 3 hours. Designed for non-handed installation, it accommodates door thicknesses ranging from 1-3/4″ to 2″, providing versatility for various entryways. With a backset of 2-3/4″ and an ANSI strike size of 4-7/8″ x 1-1/4″, this lock is easy to install and integrate into existing structures. A limited 5-year warranty underscores Yale’s commitment to quality. Whether you’re securing an office or a commercial building, the Yale MO4704LN ensures both style and security, making it a trusted choice for building professionals and homeowners alike.
Grade 1 Entry Lock
Grade 1 Entry/Office Cylindrical Lock, Monroe Lever, Conventional Cylinder, PARA Keyway, Satin Chrome Finish, Non-Handed
Yale 4700LN cylindrical locks are the idea choice for a wide variety of commercial applications where consistent quality, ease of use and installation are required at an economical price. The 4700LN Series is certified to ANSI/BHMA Grade 1 standards and is UL Fire Listed for all functions insuring reliability and peace of mind.
Your choice of a wide variety of commercial applications.
Ideal choice for a wide variety of grade 1 commercial applications where consistent quality, ease of use and installation are required at an economical price.
- Door Thickness: 1-3/4″ (44mm) to 2″ (51mm); 1-3/8″ (35mm) or 2-1/4″ (57mm), please specify on order
- Strike: ANSI 4-7/8″ x 1-1/4″ x 1-1/4″ (124mm x 32mm x 32mm) lip to center.
- Backset: 2-3/4″ (70mm)
- Handing: Non-handed
- Installation: ANSI/BHMA A156.115(-W)
- ANSI/BHMA: Certified ANSI/BHMA A156.2, Series 4000 Grade 1
- Warranty: 5 year
Attributes
Ansi: ANSI A156.2, Series 4000, Grade 1
Ansi Function: F82A
Base Material: Brass, Bronze
Bolt Projection: 1/2″
Bore Hole Diameter: 2-1/8″
Box Depth Fraction: 7-1/4″
Box Height Fraction: 3-3/4″
Box Width Fraction: 6-3/4″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: Conventional Cylinder
Cylinders Present: Single Cylinder
Door Thickness: 1-3/4″ to 2″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 04-Entry/Office
Function Family: Entrance/Office
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Keys: Cut
Latch Bore Diameter: 1″
Lever Knob: Lever
Lever Knob Design Name: Monroe
Leverknob Design: MO – Monroe Lever
Leverknob Design Family: Curved Lever
Limited Warranty: 5 Years
Lock Face Size: 1-1/8″ x 2-1/4″
Manufacturer Function: Entry
Maximum Door Thickness: 2″
Minimum Door Thickness: 1-3/4″
Of Keys: 2
Origin: United States
Pack Height: 3.75″
Pack Length: 7.25″
Pack Qty: 1
Pack Volume: 183.52 in³
Pack Width: 6.75″
Pins: 6
Product Height: 3.75″
Product Length: 7.25″
Product Width: 6.75″
Projection: 3-1/2″
Rose Escutcheon: Rose
Roseescutcheon Design: 3-1/2″ Rose Diameter
Roseescutcheon Dimensions: 3-1/2″
Screws: Combination
Series: 4700LN Grade 1 Cylindrical Lever Locks
Ship Weight: 4 lbs.
Std Keyway: PARA
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 694
Std Latch Type: Beveled Dead Latch (Guarded)
Std Strike Height: 4-7/8″
Std Strike Number: 497
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4″
Strike Dimensions: 1-1/4″ x 4-7/8″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Resources
- 4700LN Grade 1 Cylindrical Lever Locks Cut Sheet
- 4700LN Series – Grade 1 Cylindrical Locks Catalog
- 4700N Series Installation Instructions
- 5300LN Grade 2 or 4700LN Grade 1 Cylindrical Lever Locks Installation Instructions
- Electrified Wiring Instructions 5390LN/5391LN and 4790LN/4791LN
