Yale LBDY8822FL 626 Dormitory Exit Mortise Body
Yale LBDY8822FL 626 Dormitory/Exit Mortise Body is a robust Grade 1 lever mortise lock designed for dormitory and exit applications. With a sleek satin chrome finish, this lock combines aesthetics with performance, ensuring it meets the demands of commercial environments. The Yale 8800 Series Mortise Locks are built for exceptional strength and durability, featuring a reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim. Installation is user-friendly, thanks to quick lever handing and a field reversible latchbolt, allowing for flexibility in various door configurations. The lock accommodates standard door thicknesses of 1-3/4 inches and can be ordered for doors up to 3-1/4 inches thick. It is certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1 and is UL/cUL fire rated for up to 3 hours, making it a reliable choice for safety-conscious environments. Additional features include a 3/4-inch stainless steel throw latchbolt, a free-floating bevel front for easy adjustment, and a 1-1/4-inch curved lip strike. The lock comes with a 10-year mechanical warranty, ensuring long-lasting performance. Available in 17 finishes, the Yale LBDY8822FL lock not only secures but also enhances the aesthetic appeal of any door.
Dormitory/Exit Mortise Body
Grade 1 Lever Mortise Lock Body, Dormitory Function, Satin Chrome Finish
Yale 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
Lock installation is easy with quick lever handing, field reversible latchbolt and standard nonhanded strike.
The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
- ANSI/BHMA:Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL-cUL:UL/cUL fire rated up to 3 hours
- Windstorm:Certified (refer to local codes)
- Mechanism:Stainless steel
- Backset:2-3/4″
- Latchbolt:3/4″ stainless steel throw
- Door Thickness:1-3/4″ standard, to 3-1/4″ thick doors to order
- Fronts:Bevel front, free-floating to adjust from flat to standard bevel of 1/8″ in 2″
- Cylinders:Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
- Reversibility:Field reversible handing
- Strikes:1-1/4″ curved lip for 1-3/4″ door standard; other lip lengths to special order; all reversible
- Finishes:Available in 17 finishes
- Warranty:10 year mechanical
Attributes
Ansi Function: F13 – Dormitory
Commercial Residential: Commercial
Finish: 626/US26D
Finish Family: Matte Silver
Function: 22-Dormitory or Exit Lock
Grade: Grade 1
Installation: Commercial
Pack Qty: 1
Series: Yale 8800 Series Mortise Locks
Subtype: Lock Bodies
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
