Von Duprin 6221 24V US10 Electric Strike MTS/CYL 612
Von Duprin 6221 24V US10 Electric Strike, Mts/Cyl 612 offers a robust solution for secure access control in commercial settings. This Grade 1 electric strike is designed as fail secure, remaining locked during power outages, ensuring safety and compliance. With a 24 VDC operation, it features a 6″ x 1-1/4″ faceplate that easily integrates with cylindrical or mortise locks on double doors, whether in hollow metal, aluminum, or wood frames. Constructed from durable stainless steel, the Von Duprin 6221 is UL1034 listed, showcasing its resistance to forced entry and fire-rated capabilities. Its non-handed design provides flexibility, allowing installation in various configurations. The adjustable strike box effectively compensates for door or frame misalignment, enhancing reliability over time. With a static strength of 1300 lbs and dynamic strength of 70 ft-lbs, this electric strike can withstand high traffic and frequent use, boasting an endurance rating of 1,000,000 cycles. The easy installation process is complemented by two-piece plug connectors for straightforward servicing. Available in a satin bronze clear-coated finish, the Von Duprin 6221 not only meets stringent industry standards but also complements existing hardware seamlessly.
Electric Strike, Mts/Cyl 612
Grade 1 Electric Strike, Fail Secure (Electrically Unlocked) 24 VDC, 6″ x 1-1/4″ Faceplate, Fire Rated, For use with Cylindrical or Mortise Locks on Double Doors (Open Back), Hollow Metal, Aluminum, or Wood Frame, Satin Bronze Clear Coated Finish
Von Duprin electric strikes are known for their reliability, durability and security. The 6100 Series strikes are designed to withstand abuse. Their heavy-duty stainless steel construction is UL1034 listed.
Designed for use with a variety of mortise or cylindrical locksets, as well as mortise exit devices.
The 6200 Series also provides added security and traffic control.6200 Series electric strikes can be used for retrofit applications or new construction andis designed to withstand abuse.
- Non handed design provides greater flexibility
- Strike box is adjustable to compensate for misalignment of the door or frame
- Two piece plug connectors are furnished for ease of installation and for removal during strike servicing
- ANSI 156.5 Grade 1, 1500 lb hold-force rated
- UL1034 Burglary-Resistant and UL10C Electric Strike for Fire Door
- Six finishes available to suite with existing hardware
- Durable stainless steel construction
- 24 VDC standard with 12 VDC and AC operation optional
- Meets BHMA A156.31, Grade 1 for endurance and strength
- Static strength 1300 lbs
- Dynamic strength 70 ft-lbs
- Endurance 1,000,000 cycles
Attributes
Manufacturer surcharge: 7.0%
Accessible: No
Ada Compliance: No
Amp Draw: 330mA
Application: Double Door, Open Back
Baa Qualified: Yes
Burglar Rated: Yes
Commercial Residential: Commercial
Configuration: Centered
Country of origin: USA
Faceplate Size: 6″ x 1-1/4″
Finish: 612/US10
Finish Family: Matte Bronze
Fire Rated: Yes
Fire Rating: Yes {Variable}
For Use With: Cylindrical/Mortise Locks
Frame Application: Hollow Metal, Aluminum, or Wood
Frame Depth: 4-3/4″
Function: Fail Secure
Installation: Commercial
Keeper Size: Pullman Keeper
Limited Warranty: 1 Year
Operating Voltage: 24 VDC
Origin: USA
Pack Height: 2.63″
Pack Length: 10.5″
Pack Qty: 1
Pack Volume: 161.93 in³
Pack Width: 5.88″
Product Height: 1.25″
Product Length: 6″
Product Width: 1.75″
Ramp Cut Out: 3-7/8″
Restrictions: None
Series: 6200 Series Electric Strikes
Ship Weight: 2 lbs.
Subtype: Electric Strikes
Type: Electric Strikes, Bolts, Magnets
Ul Listing: UL 10C, 1034
Unit of Measure: Each
