Description
Von Duprin 6221 24V US4 Electric Strike, MTS/CYL 606
Von Duprin 6221 24V US4 Electric Strike, Mts/Cyl 606 offers a robust security solution with its Grade 1 construction and fail secure functionality. Designed for double doors with an open back, this electric strike is compatible with both cylindrical and mortise locks, making it a versatile choice for various applications. Its durable satin brass finish not only enhances aesthetic appeal but also ensures longevity in high-traffic environments. Constructed from heavy-duty stainless steel, the 6221 electric strike is UL1034 listed for burglary resistance and UL10C rated for fire door applications, providing peace of mind in terms of safety and security. The adjustable strike box compensates for door or frame misalignment, allowing for seamless installation.With an operating voltage of 24 VDC and an impressive hold force rating of 1500 lbs, this electric strike is engineered to withstand significant abuse, ensuring reliable performance. It meets BHMA A156.31 Grade 1 standards for endurance and strength, boasting a remarkable endurance rating of 1,000,000 cycles.Ideal for commercial installations, the Von Duprin 6221 electric strike combines functionality with durability, making it an essential component for any secure entryway.
Electric Strike, Mts/Cyl 606
Grade 1 Electric Strike, Fail Secure (Electrically Unlocked) 24 VDC, 6″ x 1-1/4″ Faceplate, Fire Rated, For use with Cylindrical or Mortise Locks on Double Doors (Open Back), Hollow Metal, Aluminum, or Wood Frame, Satin Brass Finish
Von Duprin electric strikes are known for their reliability, durability and security. The 6100 Series strikes are designed to withstand abuse. Their heavy-duty stainless steel construction is UL1034 listed.
Designed for use with a variety of mortise or cylindrical locksets, as well as mortise exit devices.
The 6200 Series also provides added security and traffic control.6200 Series electric strikes can be used for retrofit applications or new construction andis designed to withstand abuse.
- Non handed design provides greater flexibility
- Strike box is adjustable to compensate for misalignment of the door or frame
- Two piece plug connectors are furnished for ease of installation and for removal during strike servicing
- ANSI 156.5 Grade 1, 1500 lb hold-force rated
- UL1034 Burglary-Resistant and UL10C Electric Strike for Fire Door
- Six finishes available to suite with existing hardware
- Durable stainless steel construction
- 24 VDC standard with 12 VDC and AC operation optional
- Meets BHMA A156.31, Grade 1 for endurance and strength
- Static strength 1300 lbs
- Dynamic strength 70 ft-lbs
- Endurance 1,000,000 cycles
Attributes
Manufacturer surcharge: 7.0%
Accessible: No
Ada Compliance: No
Amp Draw: 330mA
Application: Double Door, Open Back
Baa Qualified: Yes
Burglar Rated: Yes
Commercial Residential: Commercial
Configuration: Centered
Country of origin: USA
Faceplate Size: 6″ x 1-1/4″
Finish: 606/US4
Finish Family: Matte Brass
Fire Rated: Yes
Fire Rating: Yes {Variable}
For Use With: Cylindrical/Mortise Locks
Frame Application: Hollow Metal, Aluminum, or Wood
Frame Depth: 4-3/4″
Function: Fail Secure
Installation: Commercial
Keeper Size: Pullman Keeper
Limited Warranty: 1 Year
Operating Voltage: 24 VDC
Origin: USA
Pack Height: 2.63″
Pack Length: 10.5″
Pack Qty: 1
Pack Volume: 161.93 in³
Pack Width: 5.88″
Product Height: 1.25″
Product Length: 6″
Product Width: 1.75″
Ramp Cut Out: 3-7/8″
Restrictions: None
Series: 6200 Series Electric Strikes
Ship Weight: 2 lbs.
Subtype: Electric Strikes
Type: Electric Strikes, Bolts, Magnets
Ul Listing: UL 10C, 1034
Unit of Measure: Each
Resources
- 5100/6100/6200/6300 Series Electric Strikes Service Manual
- 6000 Electric Strike Installation Instructions
- 6000 Electric strike DSReplacement Kit Installation Instructions
- 6000 Entry Buzzer Wiring Diagram
- 6000 Series Electric Strike Refurbish Kit Installation Instructions
- 6200 Series Electric Strikes Cut Sheet
- 6210/6210DS Installation Instructions
- 6211 WF Electric Strike Wood Door Template
- 6211/6211DS Single Door Mortise or Cylindrical Installation Instructions
- 6211AL Electric Strike Aluminum Door Installation Template
- 6211AL/ALDS Installation Instructions
- 6211WF/WFDS Installation Instructions
- 6212 WF Electric Strike Wood Door Template
- 6212/6212DS Installation Instructions
- 6212WF/WFDS Installation Instructions
- 6213/6213DS Installation Instructions
- 6214/6214DS Installation Instructions
- 6215/6215DS Installation Instructions
- 6216/6216DS Installation Instruction
- 6221 Electric Strike Wood Door Template
- 6221 Installation Instructions
- 6222 Installation Instructions
- 6223 Electric Strike Wood Door Template
- 6223/6223DS Installation Instructions
- 6224/6224DS Installation Instructions
- 6224AL/6224ALDS Installation Instructions
- 6225 Installation Instructions
- 6226/6226DS Installation Instructions
- Norton Rixson Low Energy Operator Brochure
- Von Duprin Finishes Chart
