TownSteel Entrance Mortise Lock – Secure Your Property

Description

TownSteel MSE-W-Q-20-626 Mortise Lock for Entrance

TownSteel MSE-W-Q-20-626 Entrance Mortise Lock delivers exceptional security and durability for high-traffic environments such as office buildings, schools, and industrial complexes. This ANSI Grade 1 heavy-duty lock is certified under BHMA A156.13-2012 and UL 10C, boasting a robust 3-hour fire rating. Its sleek satin chrome finish not only enhances aesthetics but also provides long-lasting resistance against wear and tarnishing. Designed with a wide escutcheon measuring 8-5/32″ in height and 2-41/64″ in width, the MSE-W-Q-20-626 effectively conceals extra holes from existing door preparations. The lock features a single cylinder with a Schlage C keyway, ensuring compatibility with various key systems, and is available in both clutched and non-clutched mortise chassis options.The Quest Lever design adds a modern touch while ensuring ease of use. With a standard door thickness of 1-3/4″ and a variety of lever styles available in eight finishes, this mortise lock can seamlessly integrate into any commercial setting. Each unit includes two cut keys, providing convenience without compromising on security. Elevate your door hardware with the reliability and performance of the TownSteel MSE-W-Q-20-626 Entrance Mortise Lock.

Entrance Mortise Lock

ANSI Grade 1 Heavy Duty Wide Escutcheon Mortise Lock, Quest Lever, Single Cylinder Entrance/Apartment, Schlage C keyway, Satin Chrome

The MS series Mortise Lock is BHMA A156.13-2012 certified Grade 1, and UL 10C 3-hour rated. The “W” Escutcheon is 8- 5/32″ in height and 2-41/64″in width. It’s specially designed to cover extra holes of exiting door prep. Both clutched and non-clutched mortise chassis are available. 8 commercial lever and knob in 8 BHMA finishes to select from.

Ideal for high-traffic applications like office buildings, schools and industrial areas.

TownSteel’s Mortise Locks are BHMA A156.13-2012 certified Grade 1 and UL 10C 3-hour rated. Both clutched and non-clutched mortise chassis are available with a variety of lever designs from which to choose.

• Designed for high-traffic commercial applications: Schools, Universities, Office Buildings, Industrial Complexes
• A variety of trims and finishes available including stainless steel
• Most BHMA functions are avialable in Rigid and Clutched configurations
• Door Thickness: 1-3/4″ standard with others upon request

Attributes

Manufacturer surcharge: 14.0%

Ansi Function: F20 – Entry/Office

Cylinder Type: Mortise Cylinder

Door Thickness: 1-3/4 In.

Finish: 626/US26D

Function: 20-Entrance/Apartment/Dormitory

Grade: Grade 1

Handing: Not Handed

Keying: Keyed Different

Keys: Cut

Leverknob Design: Q – Quest Lever

Of Keys: 2

Pack Qty: 1

Roseescutcheon Design: W – Escutcheon

Series: TownSteel Mortise Locks

Std Keyway: C

Std Latch Backset Dim: 2-3/4 In.

Subtype: Mortise Lock

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each

Resources

• 2024 TownSteel Price Book
