Description
LCN 4040XP-TBWMS 616 Thru-Bolt, Wood-Machine, US11
LCN 4040XP-TBWMS 616 Thru-bolt, Wood-Machine US11 combines durability and flexibility in a heavy-duty door closer designed for institutional and high-traffic environments. This closer is engineered to excel in demanding applications, boasting a robust design that surpasses industry standards for reliability and performance. With a 44% increased bearing load capacity and the strongest pinion ever featuring a 3/4″ journal diameter, the LCN 4040XP ensures enhanced strength and longevity. Its innovative V-shield™ seal offers a 20% longer lifespan, while the cast iron body and forged steel arm provide exceptional durability against wear and tear. The closer is non-handed, making installation straightforward for either right or left swinging doors. The LCN 4040XP is UL and cUL listed, ensuring compliance with safety standards, and meets ADA requirements for accessibility. It can be installed in various configurations, including hinge side, top jamb, or parallel arm. Additionally, this model supports custom finishes for aesthetic versatility and can be adjusted for doors up to 5’0″ for interiors and 4’0″ for exteriors. With a 30-year limited warranty, the LCN 4040XP offers remarkable value for commercial applications, proving to be a steadfast solution for any heavy-use environment.
Thru-bolt, Wood-Machine US11
Thru Bolts with Wood and Machine Screw Pack, Satin Bronze Blackened Satin Relieved Clear Coated Finish
LCN’s most durable and flexible heavy duty closer designed for institutional and other demanding high traffic applications.
Durable, non-handed, heavy duty closer designed for the most demanding, high-use and abuse applications.
The LCN 4040XP sets a new standard for reliability, longevity and value with a beefier design and extraordinary performance testing that goes far beyond industry requirements. LCNbuilt the 4040XP from the inside out, combining tougher, bolder construction with proven LCN technology. The result is a closer that’s stronger, smarter and delivers remarkable value in a variety of applications.
- 44% increased bearing load capacity
- Strongest pinion ever, at 3/4″ journal diameter
- Widest bearing ever,at 5/8″
- Stronger pinion teeth
- New V-shield™ seal with 20% longer life
- XP = eXtra Protection in real world applications
- Cast Iron
- Forged Steel Arm
- Double Heat Treated Steel Pinion
- All Weather Fluid
- Non-Handed
- LCN® Fast™ Power Adjust
- Fast & Accurate Installation
- UL & cUL Listed
- Tested and certified under ANSI Standard A156.4, grade one
- Non-sized cylinder is adjustable for interior doors to 5’0” and exterior doors to 4’0″
- Closer can mount hinge side, top jamb, or parallel arm (with PA bracket) on either right or left swinging doors
- Closers to meet ADA requirements
- Standard or optional custom powder coat finish
- Optional plated finish on metal cover, arm and fasteners
- Optional SRI primer for installations in corrosive conditions is available with powder coat only
- UL and cUL listed for self-closing doors without hold-open
- 4040XP can be used with all 4040 accessories
Attributes
Manufacturer surcharge: 4.5%
Application: For 4040XP Series Door Closers
Baa Qualified: Yes
Base Material: Bronze
Commercial Residential: Commercial
Country of origin: USA
Finish: 616/US11
Finish Family: Dark Bronze
Grade: Grade 1
Installation: Commercial
Limited Warranty: 30 Years
Origin: USA
Pack Qty: 1
Series: 4040XP Series Surface Mounted Closers
Subtype: Door Closer Parts
Type: Door Closers and Operators
Unit of Measure: Each
