Sliding Door Hardware, HAWA Junior 80/M Set by Hafele

Description

Hafele 940.84.012 HAWA Junior 80/M Sliding Door Hardware Set

Hafele 940.84.012 Sliding Door Hardware, HAWA Junior 80/M, Set offers an exceptional solution for creating stylish and functional single glass door applications. Designed for both internal and external use, this sliding door system ensures a smooth and quiet operation, making it ideal for residential and commercial spaces alike. With a load-bearing capacity of up to 176 lbs (80 kg), it accommodates various door materials, including wood and glass, providing versatility in design. The system features adjustable retention springs for track stops, allowing for precise control and customization. Vertical and lateral adjustments ensure a perfect fit, while the robust steel suspension can be welded or bolted for added strength. This set includes all necessary components, such as running gears, suspension plates, track stoppers, a lower guide, and a buffer, streamlining the installation process. For users requiring bi-parting metal sliding doors, simply order two sets. Note that the lower guide channel and upper track are sold separately. An installation plan is also available upon request to assist in your planning and execution. Hafele’s commitment to quality and functionality is evident in this sliding door hardware set, making it a smart choice for any project.

Sliding Door Hardware, HAWA Junior 80/M, Set

for single glass door

Smooth quiet operation Track stop with adjustable retention spring Vertical and lateral adjustment Steel suspension for welding or bolting For internal or external use

Item numbers are valid only for 1 piece, when ordering individual components please state the desired amount. For 2 bi-parting metal sliding doors please order 2 sets. Lower guide channel and upper track have to be ordered separately. Installation plan for planning and execution available upon request.

Attributes

Area of application: For 1 and 2 sliding glass doors

For door material: wood, glass

For door weight: ≤80 kg

Load bearing capacity: 176 lbs.

Material/finish: Aluminium

Max. door weight: 176.00 lb

Number of doors: 1.00

Number of doors per system max.: 2

Running position: Top

Suitable for: Protected outdoor area

Supplied with: 2 x running gear 2 x suspension plate 2 x track stopper 1 x lower guide 1 x buffer

Resources

• Manufacturer information
• TCH_Architectural_Hardware_ 2022 | Page 1.377
