Description
Schlage B560P 613 S123 Single Cylinder Deadbolt
Schlage B560P 613 S123 Single Cylinder Deadbolt offers robust security and exceptional versatility, designed specifically for commercial applications. This Grade 2 deadbolt features a keyed outside and a thumbturn inside, providing convenience without compromising safety. With its 6-pin cylinder and a bolt projection of 1 inch, the B560P ensures reliable performance across various door thicknesses, accommodating doors ranging from 1-3/8 inches to 1-7/8 inches.The deadbolt is crafted with an adjustable backset and integrates an anti-pry shield to protect the latch, enhancing its resistance to tampering. The thicker metal security strike on the jamb side, equipped with an additional screw for deeper anchoring, adds another layer of strength. The seamless steel latch construction and a 10% larger diameter deadbolt contribute to its superior durability. This model also meets UL 10B and UL 10C requirements, reflecting its high standards for fire and safety. Finished in a dark oxidized satin bronze, the B560P not only enhances the aesthetic of any door but also ensures longevity in high-traffic environments. With a limited three-year warranty and compatibility with multiple Schlage cylinder formats, this deadbolt stands as a reliable choice for those seeking top-tier security solutions.
Single Cylinder Deadbolt
Grade 2 Single Cylinder Deadbolt, Keyed Outside/Thumbturn Inside, 6-Pin Cylinder, 12-288 Latch, 10-094 Strike, 1-3/8″ – 1-7/8″ Door Thickness, Dark Oxidized Satin Bronze Oil Rubbed Finish
The B500 Series deadbolt from Schlage offers some of thetoughest, most versatile Grade 2 deadbolts in the business.Designed by locksmiths for locksmiths, B500 Series can acceptevery Schlage cylinder format and fit virtually every door youservice. It features enhanced lock strength on the jamb side ofthe door and is offered in most functions with optional single- ordual-sided lock status indicator trim options. Large window sizeand Schlages patented 180-degree visibility will change foreverthe way you look at deadbolts.
A revolutionary new deadbolt that delivers higher security and tougher performance.
Designed by locksmiths for locksmiths, the B500 Series deadbolt can be fitted with any Schlage cylinder, fits virtually every door you service, enhances lock strength on the jamb side of the door and will change forever the way you look at deadbolts.
- Adjustable backset with lock-in-place helix design
- Integrated anti-pry shield protects latch
- Thicker metal security strike back-up on jamb side
- Security strike on jamb has third screw for stronger, deeper anchoring
- Added space inside strike box for true deadlatch
- Seamless steel latch construction along the entire length of the bolt housing
- 10% larger diameter deadbolt
- Zinc bolt with spinning hardened steel pin inside
- Tapered front housing that can’t be unscrewed
- Integrated trim piece for fewer pieces out of the box
- Large, easy-to-use, ADA compliant thumbturn
- Meets UL 10B andd UL 10C requirements
Attributes
Manufacturer surcharge: 4.5%
Ansi: A156.36, 2010
Ansi Function: E0152 – Single Cylinder Deadbolt
Baa Qualified: Yes
Bolt Projection: 1″
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: 6-Pin Cylinder
Door Thickness: 1-3/8″ – 1-7/8″
Dust Box: Metal
Finish: 613/US10B
Finish Family: Dark Bronze
Grade: Grade 2
Installation: Commercial
Keying: Keyed 5
Keys: 5-pin, C section
Limited Warranty: 3 Years
Lock Face Size: 1″ x 2-1/4″
Mechanical Option: Keyed Outside x Thumbturn Inside
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Product Height: 4.13″
Product Width: 2.54″
Series: B500 Series Deadbolts
Std Latch Backset Dim: Adjustable for 2-3/8″ or 2-3/4″
Std Latch Number: 12-288
Std Latch Type: Square Corner
Std Strike Height: 2-3/4″
Std Strike Number: 10-094
Std Strike Type: Square Corner
Std Strike Width: 1-1/8″
Subtype: Deadbolts
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- B500 Series Data Sheet
- B500 Series Deadbolts Cut Sheet
- B500 Series Installation Instructions
- B560, 61, 62, 63 Template
- B571 Template
- Schlage B Series Indicator Pricing Addendum
- Schlage B Series Service Manual
- Von Duprin Finishes Chart
