Schlage Grade 1 Electric Mortise Lock – No Database, Fail Secure

Description

Schlage L9092EUJ 05A 622 Grade 1 Electric NoDB Fail Secure Instructions

Schlage L9092EUJ 05A 622 Grade 1 Electric Mortise Lock offers a robust solution for commercial security needs. This Grade 1 lock features a fail secure function and is designed for heavy-duty applications, ensuring maximum safety and reliability. With its Schlage FSIC Prep Less Core, the L9092EUJ provides versatility, allowing for easy core replacement as your security needs evolve. The lock is equipped with a universal input voltage capacity, accepting either 12 or 24VDC, and offers a unique user-selectable fail safe/fail secure function that can be adjusted simply by flipping a switch within the lock case. Additionally, the innovative RX switch enhances lever detection sensitivity while maintaining security, enabling field installation without the need to open the lock. Designed for doors with a thickness of 1-3/4 inches, the L9092EUJ features a sleek flat black coated finish (622/US19) and an A Rose design, making it a stylish yet functional choice. The lock also supports ADA compliance and is fire-rated for up to 3 hours, ensuring safety in emergencies. Its field-reversible handing allows for flexible installation, making it an ideal choice for a range of commercial environments.

Grade 1 Elec noDB, Fail Sec

Grade 1 Fail Secure Electric Mortise Lock, Schlage FSIC Prep Less Core, 05 Lever, A Rose, Flat Black Coated Finish, Field Reversible

The Schlage L909x Series is the next generation of electrified mortise lock. The series utilizes the latest technology to offer tremendous utility and flexibility. The universal input voltage will accept 12 or 24VDC and fail safe/fail secure functions are user selectable in the field by flipping a switch in the lock case. The all new RX switch monitors the inside lever with enhanced detection level that balances security with lever sensitivity, and can be added in the field without opening the lock case.

Attributes

Manufacturer surcharge: 4.5%

Accessible: Yes

Ada Compliance: Yes

Amp Draw: 400mA

Bolt Projection: 3/4″

Commercial Residential: Commercial

Cylinder Type: Schlage FSIC Prep Less Core

Door Thickness: 1-3/4″

Dust Box: Plastic

Finish: 622/US19

Finish Family: Black

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 9092EU-Fail Secure

Grade: Grade 1

Handing: Field Reversible

Installation: Commercial

Leverknob Design: 05 Lever

Limited Warranty: 1 Year

Lock Face Size: 8″ x 1-1/4″

Operating Voltage: 12VDC/24VDC

Pack Qty: 1

Power: Hard Wired

Roseescutcheon Design: A Rose

Screws: Combination

Series: L9090 Series Electrified Mortise Lock

Std Strike Height: 4-7/8″

Std Strike Number: 10-072

Std Strike Type: ASA

Std Strike Width: 1-1/4″

Subtype: Electric Mortise Lock

Type: Electric Locks

Unit of Measure: Each
