Schlage Grade 1 Electric Mortise Lock – Fail Safe Electric Lock

Description

Schlage L9092ELB 01B 626 Grade 1 Electric NoDB Fail Safe Lock

Schlage L9092ELB 01B 626 Grade 1 Elec noDB, Fail Safe is a robust and reliable electric mortise lock designed for commercial applications. This Grade 1 lock features a fail-safe function, ensuring that in the event of a power failure, the lock will unlock, enhancing safety and accessibility. The lock is prepped for a less core SFIC cylinder, allowing for flexible keying options. With its satin chromium plated finish, the L9092ELB not only provides durability but also an elegant matte silver appearance that complements any commercial setting. The field-reversible handing allows for easy installation on doors with varying configurations, and its compatibility with universal input voltage (12 or 24VDC) makes it adaptable to different electrical systems. The innovative RX switch monitors the inside lever with enhanced sensitivity, balancing security and usability. Additionally, this lock is designed for doors with a thickness of 1-3/4 inches and includes a plastic dust box for added protection. This electric mortise lock is fire rated for up to 3 hours, providing peace of mind in emergency situations. Backed by a limited 1-year warranty, the Schlage L9092ELB is an excellent choice for any commercial space looking for advanced security and reliability.

Grade 1 Elec noDB, Fail Safe

Grade 1 Fail Safe Electric Mortise Lock, SFIC Prep Less Core, 01 Lever, B Rose, Satin Chromium Plated Finish, Field Reversible

The Schlage L909x Series is the next generation of electrified mortise lock. The series utilizes the latest technology to offer tremendous utility and flexibility. The universal input voltage will accept 12 or 24VDC and fail safe/fail secure functions are user selectable in the field by flipping a switch in the lock case. The all new RX switch monitors the inside lever with enhanced detection level that balances security with lever sensitivity, and can be added in the field without opening the lock case.

Attributes

Manufacturer surcharge: 4.5%

Accessible: Yes

Ada Compliance: Yes

Amp Draw: 400mA

Base Material: Brass or Bronze

Bolt Projection: 3/4″

Commercial Residential: Commercial

Cylinder Type: SFIC Prep Less Core

Door Thickness: 1-3/4″

Dust Box: Plastic

Finish: 626/US26D

Finish Family: Matte Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 9092EL-Fail Safe

Grade: Grade 1

Handing: Field Reversible

Installation: Commercial

Leverknob Design: 01 Lever

Limited Warranty: 1 Year

Lock Face Size: 8″ x 1-1/4″

Operating Voltage: 12VDC/24VDC

Pack Qty: 1

Power: Hard Wired

Roseescutcheon Design: B Rose

Screws: Combination

Series: L9090 Series Electrified Mortise Lock

Std Strike Height: 4-7/8″

Std Strike Number: 10-072

Std Strike Type: ASA

Std Strike Width: 1-1/4″

Subtype: Electric Mortise Lock

Type: Electric Locks

Unit of Measure: Each
