Description
Schlage B562P 626 KA4 Double Cylinder Deadbolt
Schlage B562P 626 KA4 Double Cylinder Deadbolt offers exceptional security with its Grade 2 rating and dual-key access for both the outside and inside. This robust deadbolt features a 6-pin cylinder and is compatible with doors ranging from 1-3/8″ to 1-7/8″ in thickness, making it a versatile choice for various commercial applications. Designed with the input of locksmiths, the B500 Series is engineered for enhanced strength and reliability, particularly on the jamb side. Key features include an adjustable backset with a lock-in-place helix design and an integrated anti-pry shield that safeguards the latch. The thicker metal security strike enhances durability, while the tapered front housing is designed to resist tampering. The deadbolt’s 1″ bolt projection, combined with a seamless steel latch construction, ensures robust performance. Additionally, the large ADA-compliant thumbturn provides ease of use. Meeting UL 10B and UL 10C requirements, it comes with a limited 3-year warranty for peace of mind. With its satin chrome finish and sturdy build, the Schlage B562P is not just a practical choice but also an aesthetically pleasing addition to your security measures. Ideal for any professional or knowledgeable homeowner, this deadbolt redefines the standard for door security.
Double Cylinder Deadbolt
Grade 2 Double Cylinder Deadbolt, Keyed Outside/Keyed Inside, 6-Pin Cylinder, 12-288 Latch, 10-094 Strike, 1-3/8″ – 1-7/8″ Door Thickness, Satin Chrome Finish
The B500 Series deadbolt from Schlage offers some of thetoughest, most versatile Grade 2 deadbolts in the business.Designed by locksmiths for locksmiths, B500 Series can acceptevery Schlage cylinder format and fit virtually every door youservice. It features enhanced lock strength on the jamb side ofthe door and is offered in most functions with optional single- ordual-sided lock status indicator trim options. Large window sizeand Schlage¬Ãs patented 180-degree visibility will change foreverthe way you look at deadbolts.
A revolutionary new deadbolt that delivers higher security and tougher performance.
Designed by locksmiths for locksmiths, the B500 Series deadbolt can be fitted with any Schlage cylinder, fits virtually every door you service, enhances lock strength on the jamb side of the door and will change forever the way you look at deadbolts.
- Adjustable backset with lock-in-place helix design
- Integrated anti-pry shield protects latch
- Thicker metal security strike back-up on jamb side
- Security strike on jamb has third screw for stronger, deeper anchoring
- Added space inside strike box for true deadlatch
- Seamless steel latch construction along the entire length of the bolt housing
- 10% larger diameter deadbolt
- Zinc bolt with spinning hardened steel pin inside
- Tapered front housing that can’t be unscrewed
- Integrated trim piece for fewer pieces out of the box
- Large, easy-to-use, ADA compliant thumbturn
- Meets UL 10B andd UL 10C requirements
Attributes
Manufacturer surcharge: 4.5%
Ansi: A156.36, 2010
Ansi Function: E0142 – Double Cylinder Deadbolt
Baa Qualified: Yes
Bolt Projection: 1″
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: 6-Pin Cylinder
Door Thickness: 1-3/8″ – 1-7/8″
Dust Box: Metal
Finish: 626/US26D
Finish Family: Matte Silver
Grade: Grade 2
Installation: Commercial
Keying: Keyed Alike in Sets of 4
Keys: 5-pin, C section
Limited Warranty: 3 Years
Lock Face Size: 1″ x 2-1/4″
Mechanical Option: Keyed Outside x Keyed Inside
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Product Height: 4.13″
Product Width: 2.54″
Series: B500 Series Deadbolts
Std Latch Backset Dim: Adjustable for 2-3/8″ or 2-3/4″
Std Latch Number: 12-288
Std Latch Type: Square Corner
Std Strike Height: 2-3/4″
Std Strike Number: 10-094
Std Strike Type: Square Corner
Std Strike Width: 1-1/8″
Subtype: Deadbolts
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Upc: 43156121083
Resources
- B500 Series Data Sheet
- B500 Series Deadbolts Cut Sheet
- B500 Series Installation Instructions
- B560, 61, 62, 63 Template
- B571 Template
- Schlage B Series Indicator Pricing Addendum
- Schlage B Series Service Manual
- Von Duprin Finishes Chart
