Sargent Storeroom Key Unlocks Exit Trim – RHR Right Hand Reverse

Description

Sargent LC-706-4-ETL-BSP RHR Storeroom Exit Trim, Less 41 Mortise Cylinder, RHR L Lever, Black Suede

Sargent LC-706-4-ETL-BSP RHR Storeroom offers an exceptional blend of security and convenience, making it an ideal choice for panic devices and exit alarms. Designed with a key unlock feature, this exit trim allows for easy operation and relocks automatically when the key is removed, ensuring peace of mind and enhanced safety. The trim is compatible with a variety of Sargent exit devices, including the AD8406, MD8406, AD8606, and MD8606, and is sold separately from the exit device. Constructed with durability in mind, the trim is non-handed and through-bolted to the chassis, providing a secure fit. The 700 series ET control can be utilized with other exit devices, enhancing its versatility. Featuring a sleek black suede powder coat finish, the LC-706-4-ETL-BSP combines aesthetics with functionality. Additionally, this storeroom trim supports various ANSI functions, including passage only and key-based locking/unlocking options, catering to diverse needs. With an easy-operating lever handle, the Sargent LC-706-4-ETL-BSP ensures one-hand operation for added convenience. For those looking for a reliable and stylish solution for their security needs, this storeroom exit trim is an excellent choice.

Storeroom (Key Unlocks Exit Trim, Relocks When Key is Removed), Less 41 Mortise Cylinder, Escutcheon with L Lever, RHR Right Hand Reverse, BSP Black Suede Powder Coat (Works with AD8406, MD8406, AD8606, MD8606)

Notice: The info below is not item specific.

The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.

Features:

• ANSI/BHMA Finishes
• Easy operating lever handle allows convenient one hand operation
• ET trim is not available in 32 or 32D
• Stainless steel levers are available

Functions:

• 04: Key retracts latch #34 cylinder supplied. ANSI 03
• 10: No O/S operation or cylinder (pull only). ANSI 02
• 28: Passage only (no cylinder). ANSI 15
• 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
• 62: Key unlocks thumbpiece, thumbpiece retracts latch/thumbpiece relocks when key is removed #34 cylinder supplied. ANSI 06
• 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 and I/S #44. ANSI 07
• 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
• 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
• 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
• 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied

Finishes:

• 0-3/605 – Bright brass, clear coated
• 0-4/606 – Satin brass, clear coated
• 0-9/611 – Bright bronze, clear coated
• 1-0/612 – Satin bronze, clear coated
• 10B/613 – Dark oxidized satin bronze, oil rubbed
• 10BE/613E – Dark oxidized satin bronze, equivalent
• 10BL/613L – Dark oxidized satin bronze clear coated
• 20D/624 – Dark statuary bronze lacquered
• 2-6/625 – Bright chrome plated
• 26D/626 – Satin chrome plated
• 3-2/629 – Bright stainless steel
• 32D/630 – Satin stainless steel
• BSP – Black suede powder coat
• WSP – White suede powder coat

Attributes

Alternate Codes: LC-706-4-ETL-BSP RHR, LC7064ETLBSPRHR

Category: Panic Devices & Exit Alarms, Panic Device Trims

Cylinder Type: Less Cylinder

Door Application: Panic Devices & Exit Alarms

Door Thickness: 1-3/4″

Finish Code: BSP

Finish Color: Black Suede Powder Coat

Handing: Right Handed Reverse
