Description
Sargent LC-704-ETJ-26D LHR Nightlatch Lever Trim, LHR, Satin Chrome, Less Rim Cylinder, Fits 8304-9904 Series
Sargent LC-704-ETJ-26D LHR Nightlatch Lever Trim offers a robust solution for those seeking reliable security. Designed to work seamlessly with Sargent’s 8304, 8504, 8804, 8888, 8904, and 9904 series exit devices, this lever trim features a key retracting latchbolt, allowing for convenient operation with a single hand. Its left-hand reverse configuration ensures ease of use in various applications. Constructed with durability in mind, the LC-704-ETJ is non-handed and through-bolted to the chassis, enhancing its security profile. The trim is compatible with a variety of functions, accommodating different security needs, including passage only, key unlocks, and electrified options. Available in a sleek satin chrome finish (626/US26D), this trim not only provides functionality but also adds a modern touch to any door. The stainless steel levers ensure longevity, while ANSI/BHMA finishes guarantee quality and performance. With a door thickness compatibility of 1-3/4″, the Sargent LC-704-ETJ-26D is an excellent choice for panic devices and exit alarms. Elevate your security measures with this reliable, stylish, and functional lever trim, tailored for professionals and discerning homeowners alike.
Nightlatch Lever Trim (Key Retracts Latchbolt Lever Rigid), Less 34 Rim Cylinder, Escutcheon with J Lever, LHR Left Hand Reverse, 626/US26D Satin Chrome (Works with 8304, 8504, 8804, 8888, 8904, 9904 Series)
Notice: The info below is not item specific.
The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.
Features:
- ANSI/BHMA Finishes
- Easy operating lever handle allows convenient one hand operation
- ET trim is not available in 32 or 32D
- Stainless steel levers are available
Functions:
- 04: Key retracts latch #34 cylinder supplied. ANSI 03
- 10: No O/S operation or cylinder (pull only). ANSI 02
- 28: Passage only (no cylinder). ANSI 15
- 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
- 62: Key unlocks thumbpiece, thumbpiece retracts latch/thumbpiece relocks when key is removed #34 cylinder supplied. ANSI 06
- 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 and I/S #44. ANSI 07
- 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
- 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
- 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
- 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied
Finishes:
- 0-3/605 – Bright brass, clear coated
- 0-4/606 – Satin brass, clear coated
- 0-9/611 – Bright bronze, clear coated
- 1-0/612 – Satin bronze, clear coated
- 10B/613 – Dark oxidized satin bronze, oil rubbed
- 10BE/613E – Dark oxidized satin bronze, equivalent
- 10BL/613L – Dark oxidized satin bronze clear coated
- 20D/624 – Dark statuary bronze lacquered
- 2-6/625 – Bright chrome plated
- 26D/626 – Satin chrome plated
- 3-2/629 – Bright stainless steel
- 32D/630 – Satin stainless steel
- BSP – Black suede powder coat
- WSP – White suede powder coat
Attributes
Alternate Codes: LC-704-ETJ-26D LHR, LC704ETJ26DLHR
Category: Panic Devices & Exit Alarms, Panic Device Trims
Cylinder Type: Less Cylinder
Door Application: Panic Devices & Exit Alarms
Door Thickness: 1-3/4″
Finish Code: 626
Finish Color: Brushed Chrome, Satin Chrome
Function: Key Retracts Latchbolt
Handing: Left Handed Reverse
