Description
Sargent 28-7U65 LP 03 Grade 2 Cylindrical Lever Lock
Sargent 28-7U65 LP 03 Grade 2 Cylindrical Lever offers a reliable and stylish solution for privacy needs in commercial settings. This Grade 2 cylindrical lock is designed specifically for standard-duty applications, making it ideal for use in public buildings, medical offices, hotels, and government facilities. Its bright brass finish not only enhances its aesthetic appeal but also ensures durability, surpassing ANSI/BHMA A156.2 standards for cycling and longevity. The non-handed design allows for easy installation on doors 1-3/4″ thick, with a standard 2-3/4″ backset. The P lever design provides a comfortable grip and precise lever action, promoting ease of use. Constructed with a solid steel housing and featuring a brass 1/2″ throw latch, this lock guarantees both security and functionality. Included with the lock are two nickel silver keys, and it features a 6-pin brass cylinder that can be master or grand master keyed for enhanced access control. With a fire rating of 3 hours, the Sargent 28-7U65 LP ensures peace of mind in any emergency. This cylindrical lock is a perfect blend of security, durability, and style, making it an excellent choice for any commercial application.
Grade 2 Cylindrical Lever
Grade 2 Privacy/Bathroom Cylindrical Lock, P Lever, Non-Keyed, Bright Brass Finish, Non-handed
A key-in-lever lock designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities. Exceeds ANSI/BHMA A156.2 standards for cycling and durability.
Sargent’s 7 Line Bored Lever Locks are designed with a solid feel and a precise lever action.
A key-in-lever lock designed for standard duty commercial exterior and interior doors in offices, commercial interiors, medical clinics, government facilities and public buildings. Exceeds ANSI/BHMA A156.2 Standards for cycling and durability.
- For Doors: 1-3/4″ (44mm) Thick Door standard Specify 1- for 1-3/8″ (35mm) Thick Door
- Backset: 2-3/4″ (70mm) Backset standard. Specify 20- for 2-3/8″ (60mm) Backset
- CylindricalHousing: Steel, zinc dichromate finish
- Front: Wrought brass or stainless steel; Standard — 2-1/4″ (57mm) x 1-1/8″ (29mm), with 2-3/4″ (70mm) backset Specify 20- for 2-1/4″ (57mm) x 1″ (25mm), with 2-3/8″ (60mm) backset
- Strike: Wrought brass or stainless steel 2-3/4″ Curved Lip Strike standard 4-7/8″ Curved Lip (28-) and 2-1/4″ Full Lip (14-) Strikes Optional
- Hand: Non-handed — B, L, P lever designs Handed — G and Y Coastal Series lever designs
- Latch: Brass 1/2″ (13mm) throw
- Keys: Two, nickel silver
- Cylinder: Brass, 6-pin, LA keyway standard Can be master keyed or grand master keyed
- Finishes: 03, 04, 09, 10, 10B, 10BE, 10BL 14, 15, 20D, 26 & 26D
- Door Prep: ANSI A115.2; Specify 20- for 160 Prep
Attributes
Ansi: F76
Ansi Function: F76 – Privacy
Baa Qualified: Yes
Base Material: Brass
Bolt Projection: 1/2″
Bore Hole Diameter: 2-1/8″
Box Depth Fraction: 8-1/4″
Box Height Fraction: 4-1/4″
Box Width Fraction: 6-7/8″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: Non-Keyed
Cylinders Present: Non-Keyed
Door Thickness: 1-3/4″
Dust Box: None
Finish: 605/US3
Finish Family: Polished Brass
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 65-Privacy Bathroom
Function Family: Privacy
Grade: Grade 2
Handing: Non-handed
Installation: Commercial
Latch Bore Diameter: 7/8″
Lever Knob: Lever
Lever Knob Design Name: P
Leverknob Design: P Lever
Leverknob Design Family: Curved Return Lever
Limited Warranty: 5 Year Warranty
Lock Face Size: 1-1/8 x 2-1/4″
Manufacturer Function: Privacy/Bathroom
Maximum Door Thickness: 1-3/4″
Minimum Door Thickness: 1-3/4″
Origin: United States
Pack Height: 4.25″
Pack Height 2: 9″
Pack Length: 8.25″
Pack Length 2: 20.75″
Pack Qty: 1
Pack Volume: 241.05 in³
Pack Volume 2: 2801.25 in³
Pack Width: 6.88″
Pack Width 2: 15″
Product Height: 4.25″
Product Length: 8.25″
Product Width: 6.88″
Projection: 2-1/2″
Rose Escutcheon: Rose
Roseescutcheon Design: 3-3/8″ Rose Diameter
Roseescutcheon Dimensions: 3-3/8″
Screws: Wood/Machine Screws
Series: 7-Line Bored Lever Locks
Ship Weight: 3.6 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 194493
Std Latch Type: Springlatch
Std Strike Height: 4-7/8″
Std Strike Number: 808
Std Strike Type: ANSI Curved Lip Strike
Std Strike Width: 1-1/4″
Strike Dimensions: 1-1/4″ x 4-7/8″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: ANSI A156.2, Series 4000, Grade 2, UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 10
