Description
Sargent BP-8225 32D Dormitory Lock Body
Sargent BP-8225 32D Dormitory Lock Body offers an exceptional blend of security and durability, making it a premium choice for various environments including schools, hospitals, and behavioral health facilities. This lock body is part of the renowned Sargent 8200 Series Mortise Locks and features a single cylinder with a deadbolt, designed specifically for dormitory or exit functions. Constructed with high-quality components, the BP-8225 is ANSI/BHMA Grade 2 certified, ensuring it meets rigorous cycle and strength requirements. Additionally, it is UL-cUL listed for three-hour fire doors and windstorm applications, providing peace of mind in safety-critical situations. The lock boasts a patented design, thru-bolted lever trim, and a strengthened cylinder retainer for enhanced security against unauthorized access. With 58 different functions available, this versatile lock accommodates a variety of lever designs and architectural finishes, enhancing both flexibility and aesthetics. The ease of installation and maintenance makes it ideal for building professionals, while its robust construction guarantees long-lasting performance. Backed by a 10-year warranty, the Sargent BP-8225 is a dependable choice for those seeking a reliable mortise lock solution.
Dormitory Lock Body
Sargent 8200 Series Mortise Lock, Lock Body Only, Dormitory or Exit Function, Single Cylinder with Deadbolt, Satin Stainless Steel
Constructed with the highest quality components to provide maximum security, durability and performance.
Considered the industry benchmark for all mortise locks on the market today, the robust lock is an attractive solution with a multitude of lever and escutcheon styles available.
Features:
- ANSI/BHMA Grade 2 certified for cycle and strength requirements
- UL-cUL listed for three-hour fire doors and windstorm applications
- Thru-bolted lever trim and strengthened cylinder retainer
- Available with security key systems (Degree, Signature, KESO, and XC)
- Available in 58 different functions, including electromechanical, security (freewheeling, security escutcheon, anti-vandal pull trim) and monitoring
- 6 lever designs, 2 roses/escutcheons designs, and 14 architectural finishes offered
- Available with behavioral health trim
- 10-year warranty
- Patented design and construction
Benefits:
- Strength & Reliability: Exceeds independent testing, making it the most durable mortise lock in the industry.
- Security: Security features provide resistance against unauthorized entry and vandalism.
- Flexibility & Aesthetics: Visual designwith a variety of functions, lever designs and architectural finishes match a wide range of styles and make it perfect for all types of applications (such as offices, hospitals, behavioral health environments, schools/universities).
- Ease of Installation & Maintenance: Multifunctional lockbody makes switching functions easy and reduces inventory requirements.
Attributes
Ansi Function: F13 – Dormitory
Finish: 630/US32D
Function: 25-Dormitory or Exit
Grade: Grade 1
Pack Qty: 1
Series: 8200 Line Lever Mortise Locks
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Locks Installation Instructions
- 7900/8200 Series Mortise Locks Installation Instructions
- 8200 Line Lever Mortise Locks Cut Sheet
- 8200 Mortise Sectional Indicator Trim Template
- Sargent 8200 Series Environmental Product Declaration (EPD)
- Sargent 8200 Series Mortise Locks Sell Sheet
- Video: 8200 Series Mortise Lock Installation
