Description
Von Duprin 996L-BE-17-R/V US15 RHR Passage Lever Trim – Satin Nickel 619
Von Duprin 996L-BE-17-R/V US15 RHR Passage Lever Trim 619 combines functionality and durability, making it an ideal choice for commercial settings. This Grade 1 lever trim features a passage function and is specifically designed for rim and vertical rod devices, ensuring reliable performance in high-traffic areas. The sleek satin nickel plated clear-coated finish adds a touch of sophistication while also providing resistance to wear and tear. The 996L Breakaway trim stands out as a standard offering on the 98L/99L Series devices, engineered to minimize the impact of vandalism. Its Breakaway design effectively reduces the need for costly repairs, promoting long-term value for facility managers and building owners. It’s important to note that this feature is not available on the NL (night-latch) or DT (dummy trim) versions. This trim is suitable for right hand reverse installations and is constructed from high-quality brass or bronze, highlighting its robust nature. With a reversible design, it allows for flexible installation options. The Von Duprin 996L trim is not only practical but also enhances security and accessibility in any commercial environment. Choose this trim for a reliable solution that meets your door hardware needs.
Passage Lever Trim 619
Grade 1 Lever Trim, Passage Function, Rim/Vertical Rod Prep, 17 Lever with Escutcheon, Satin Nickel Plated Clear Coated Finish, Right Hand Reverse
The 996L Breakaway trim has become the standard lever trim offering on the 98L/99L Series devices. The Breakaway design is especially effective in areas where vandalism to door hardware is a problem. The design intent is to discourage costly repairs from becoming necessary. The Breakaway feature is not available on the NL (night-latch) or DT (dummy trim) versions.
Several Von Duprin Trims are available to choose from.
Attributes
Manufacturer surcharge: 4.5%
Application: 98/99 Rim/VR Devices
Base Material: Brass or Bronze
Commercial Residential: Commercial
Cylinder Type: Non-Keyed
Design A: 17 Lever
Device Type: Trim
Finish: 619/US15
Finish Family: Matte Silver
Grade: Grade 1
Handing: Right Hand Reverse
Installation: Commercial
Mechanical Function: Passage
Pack Qty: 1
Reversible: Yes
Series: Von Duprin Trims
Subtype: Exit Device Trim
Trim Design: Lever with Escutcheon
Trim Type: Lever
Type: Exit Devices
Unit of Measure: Each
Resources
- 110, 210, 230 Series Trim Service Manual
- 110NL Cylinder Preparation Wood Door Template
- 210K Trim Wood Door Template
- 210NL Trim Wood Door Template
- 230L & 230L-BE Lever Control Wood Door Template
- 230NL Trim Wood Door Template
- 230TP & 230TP-BE Trim Wood Door Template
- 33A/35A Rim Device Trims Data Sheet
- 360/370 Series Control Trim Service Manual
- 360T, 360L, 360T-BE Control Wood Door Template
- 373-L & 373-L-BE Control Wood Door Template
- 374-T & 374-T-BE Control Wood Door Template
- 375-L & 375-L-BE Control for 5575 & 5575-F WDC Wood Door Template
- 376-T & 376-T-BE Control Wood Door Template
- 377-T & 377-T-BE Control Wood Door Template
- 386NL Trim Wood Door Template
- 388NL Cylinder Control Wood Door Template
- 392-6 Pull Wood Door Template
- 392-7 Pull Wood Door Template
- 550 DT Trim for 33/3550AWDC Wood Door Template
- 550NL Trim Wood Door Template
- 556NL Trim Wood Door Template
- 55NL Series Wood Door Template
- 606K & 606K-BE Trim Wood Door Template
- 606K-DT Trim Wood Door Template
- 606KR Trim Wood Door Template
- 608DT/NL Trim Installation Instructions
- 608NL Trim Wood Door Template
- 608TP & 608TP-BE Trim Wood Door Template
- 696/697TP/TP-BE Trim Installation Instructions
- 696NL & 697NL Trim Wood Door Template
- 696TP, 697TP, 696TP-BE, & 697TP-BE Trim Wood Door Template
- 880, 606, 608, 609 Series Trim Service Manual
- 880DT Surface Applied Trim for 8847/47-F Vertical Rod Device Installation Instructions
- 880K & 880K-BE Trim Wood Door Template
- 880K-DT Trim Wood Door Template
- 880KR Trim Wood Door Template
- 880NL Trim Wood Door Template
- 880TP & 880TP-BE Trim Wood Door Template
- 880TP & TP-BE Trim Wood Door Template
- 990 Series Outside Trim Service Manual
- 990DT EO Trim Installation Instructions
- 990NL Trim Wood Door Template
- 990TP & 990TP-BE Trim Wood Door Template
- 990TP/TP-BE/NL Trim 98/9975 Mortise Lock Device Installation Instructions
- 991K & 992L Trim Wood Door Template
- 991K-BE & 992L-BE Trim Wood Door Template
- 991K/K-BE, 992L/L-BE BE Trim Mortise Lock Device Installation Instructions
- 991KR & 992LR Trim Wood Door Template
- 992L Series Trim Active L to Rigid Conversion Kit Installation
- 994/996L & 994/996L-BE M Series Wood Door Template
- 996L & 996L-BE R/V Series Wood Door Template
- 996L-Rigid Series Wood Door Template
- M996L Series Installation Instructions
- M996L Series Retrofit Installation Instructions
- M996L/L-BE Motor Driven Electrified Trim Data Sheet
- SS333NL/TP Trim for 33/3527 Device Metal Door Installation Instructions
- Von Duprin 22/98/99 Series Device with Active Trim Cylinder Tailpiece Guide Retrofit Installation Instructions
- Von Duprin Finishes Chart
