Networx Wireless Keypad Only – 626/US26D Satin Chrome by Alarm Lock Systems Inc

Description

Alarm Lock NETDK/26D Networx Wireless Keypad, Satin Chrome, 5,000 Users, Control Panel Sold Separately

Alarm Lock Systems Inc NETDK/26D Networx Wireless Keypad offers a robust solution for secure access management. Designed to work seamlessly with the Networx NETPANEL wireless door control panel, this keypad enables entry restriction via a programmable PIN code, facilitating controlled access to your premises. The NETDK supports up to 5,000 unique user codes and maintains a comprehensive audit trail of 35,000 events, ensuring thorough monitoring of entry activities. This keypad operates on 12VDC power supplied by the NETPANEL and features an idle current of just 10mA, making it energy-efficient. With a maximum wire length of 200 feet and a recommended minimum wire size of 24 AWG, installation is flexible and straightforward. It withstands a wide operating temperature range of 14-120°F, ensuring reliability in various environments. Built with user-friendly features, the NETDK/26D includes audible low battery alerts and visible entry indicators, enhancing usability. The supplied backup battery provides approximately two hours of backup time at full load, ensuring continued operation during power outages. With weatherproof construction, this keypad is suitable for both indoor and outdoor applications, making it an ideal choice for residential or commercial properties.

Networx Wireless Keypad Only, 626/US26D Satin Chrome, Control Panel Sold Separately, 5,000 Users and Provide 35,000 Audit Trail

Notice: The info below is not item specific.

The NETDK Keypad works in conjunction with the Networx NETPANEL wireless Door control panel for restricting entry by PIN code. The NETDK wires directly to the dedicated NETPANEL, and releases an electric Strike or maglock upon authorization of an enrolled pass-code. Refer toof the NETPANEL for system Features and functionality as all of the access control decisions are made by the panel. Locks will be programmed via DL Windows software which can be used with both your existing standalone locks and new wireless locks.

Features:

• Networx Keypads NETDK / NETPDK
• Power Requirements: 12VDC supplied by NETPANEL
• Idle Current: 10mA
• Maximum Wire Length: 200 feet (61m)
• Recommended Wire Size: 24 AWG minimum
• Proximity Card Formats Supported: Alarm Lock standard 36 bit format or HID standard 26 bit format (for use with the Model NETPDK only)
• Operating Temperature: 14-120°F (–10-49°C)
• Input Power: 16.5VAC via Class 2 Plug-In 50VATransformer (supplied Model TRF-14)
• Maximum Lock Power Output Current: 1.5A @12VDC
• Primary and Secondary Relays: SPDT Form C, N/O, N/C 8A @ 30VAC or VDC
• Supplied Backup Battery: Sealed Lead Acid 4AH
• Battery Backup Time: Approximately 2 hours at full load

Attributes

Access Type: Keypad

Alternate Codes: ALANETDKUS26D, NETDK/26D, NETDK26D, NETDKUS26D

Audit Trail: 35000 Events

Battery Type: 4x, AA

Category: Access Control, Wireless

Code Length: 3-6

Door Application: Access Management

Feedback: Audible Low Battery Alert, Audible & Visible Entry Indicator

Finish Code: US26D

Manufacturer: Alarm Lock Systems Inc

Users: 5000 User Codes

Weatherproof: Yes
