Narrow CVR Crossbar Exit 626 – Von Duprin Concealed Vertical Rod Exit Device

Description

Von Duprin 5547WDCEO-F 26D LHR Narrow CVR Crossbar Exit Device 626

Von Duprin 5547WDCEO-F 26D LHR Narrow CVR Crossbar Exit 626 is a Grade 1 Concealed Vertical Rod Exit Device designed for wood doors. This exit bar features a narrow stile crossbar measuring 48 inches, ideal for fire-rated installations. Its sleek satin chrome finish complements a variety of architectural styles, making it an excellent choice for retro-inspired or historical buildings. Engineered for functionality and safety, the 5547WDCEO-F is an exit-only device that operates without trim or dogging features. It fits doors with stiles as narrow as 1 3/4 inches, accommodating both single and double door configurations with mullions. The device comes with a crossbar height of 36 13/16 inches at the center, ensuring easy access for users.Installation is straightforward with included fasteners and sex bolts for doors ranging from 1 3/4 inches to 2 1/4 inches thick. The concealed vertical rod design provides a clean aesthetic while enhancing security in commercial environments. Additionally, this model is field reversible, allowing for flexible application. With a limited warranty of three years, the Von Duprin 5547WDCEO-F assures reliability and durability in demanding settings, making it a trusted choice for building professionals.

Narrow CVR Crossbar Exit 626

Grade 1 Concealed Vertical Rod Wood Door Exit Bar, Narrow Stile Crossbar, 48″ Fire-Rated Device, Exit Only, Less Trim, Less Dogging, Satin Chrome Finish, Field Reversible, Left Hand Reverse

The 55 Series from Von Duprin are exit device crossbars with a classic design. The 55 Series is a narrow stile device and commonly used in retro-inspired architecture and historical buildings.

Concealed Vertical Rod Exit Device, Dummy Trim.

55 Seriesdevices for all types of single and double doors with mullion, UL listed for accident hazard installations. Fits doors stiles as narrow as 1 3/4″ (44 mm).

• Device functions Device ships EO/DT/NL/L
• Crossbar length 42″ (1067 mm)
• Crossbar height to finished floor 36 13/16″ (935 mm) at center
• Lock stile case 7 1 /4″ x 1 3 /16″ x 2 1 /4″ (184 mm x 30 mm x 57 mm)
• Hinge stile case 7 1 /4″ x 1 3 /16″ x 2 1 /4″ (184 mm x 30 mm x 57 mm)
• Crossbar tubing 1″ (25 mm)
• Projection Crossbar neutral – 3 3/4″ (95 mm) Crossbar depressed – 2 3/8″ (60 mm)
• Latch bolt 3/4″ (19 mm), throw
• Fasteners and Sex bolts (SBN) Includes screw pack for 1 3/4″ (44 mm) and 2 1/4″ (57 mm) thick metal or wood doors. Sex nuts and bolts included.

Attributes

Manufacturer surcharge: 4.5%

Base Material: Brass or Bronze

Commercial Residential: Commercial

Cylinder Type: Non-Keyed

Device Length: 48″

Device Type: Concealed Vertical Rod

Dogging Options: Less Dogging

Door Height: 96″

Door Material: Wood

Door Thickness: 1-3/4″

Door Width: 36″ to 48″

Finish: 626/US26D

Finish Family: Matte Silver

Fire Rated: Yes

Fire Rating: Yes {Variable}

Grade: Grade 1

Handing: Left-Hand Reverse

Includes Cylinders: No

Includes Trim: No

Installation: Commercial

Limited Warranty: 3 Years

Mechanical Function: Exit Only, Accepts Various Trim

Mechanical Options: Fire Rated

Minimum Stile Size: 4-3/4″

Pack Qty: 1

Physical Appearance: Narrow Stile Crossbar

Product Length: 48″

Reversible: Yes

Series: 55 Series Narrow Style Crossbar Devices

Strike Bottom: 304L

Subtype: Concealed Vertical Rod Exit Devices

Top Strike: 378

Trim Type: Less Trim

Type: Exit Devices

Unit of Measure: Each

Resources

• 55 Series Exit Device Service Manual
• 55 Series Narrow Style Crossbar Devices Cut Sheet
• 5547WDC & 5547WDC-F Series Wood Door Template
• 5575 & 5575-F Mortise Lock Wood Door Template
• Von Duprin Finishes Chart
