Mortise Crossbar Exit 605 – Von Duprin

Description

Von Duprin 8875L US3 LHR L/TRIM Mortise Crossbar Exit 605

Von Duprin 8875L US3 LHR L/TRIM Mortise Crossbar Exit 605 is a Grade 1 mortise exit device designed for durability and versatility in both commercial and institutional settings. This wide stile crossbar device measures 48 inches and features a classroom function, making it ideal for areas requiring easy access while maintaining security. Engineered for both single and double doors, this exit device is UL listed for accident hazard installations and accommodates stock hollow metal doors with 86 cutouts and stiles as narrow as 4 3/4 inches. The factory-handed design can be easily field-reversed, allowing for installation flexibility. Its 3/4-inch anti-friction latch bolt is also reversible without removing the device from the door, ensuring seamless operation. The Von Duprin 8875L utilizes hex key dogging for secure locking, while the faceplate includes an adjustable bevel. With a striking bright brass finish, this device not only provides functionality but also enhances aesthetic appeal. Fasteners and a comprehensive screw pack for both metal and wood doors are included, simplifying the installation process. For professionals seeking a reliable, efficient exit solution, the Von Duprin 8875L is an exemplary choice that meets a wide range of operational needs while ensuring compliance with safety standards.

Mortise Crossbar Exit 605

Grade 1 Mortise Exit Bar, Wide Stile Crossbar, 48″ Device, Classroom Function, Less Trim, Hex Key Dogging, Bright Brass Finish, Field Reversible, Left Hand Reverse

8875 mortise lock devices or all types of single or double doors, UL listed for accident hazard installations. Fits stock hollow metal doors with 86 cutouts and door stiles as narrow as 4 3/4″ (121 mm). This device is field reversible but comes handed from factory. The 7500 mortise lock is equipped with a 3/4″ (19 mm) anti-friction latch bolt which is field reversible without removing the lock from the door. It has a non-handed auxiliary bolt for deadlocking and a faceplate with an adjustable bevel. Field selection of functions are furnished standard. TP and K function may be field selected by turning down a set screw in mortise lock body. Electric locking or unlocking options are available.

Fits stock hollow metal doors with 86 cutouts and door stiles as narrow as 4 3/4″ (121 mm).

8875 Series is for all types of single and double doors with mullion, UL listed for accident hazard installations.

• Device functions Device ships EO, DT, NL, TP, K, L
• Handing Handed
• Crossbar length 42″ (1067 mm) field sizable Device centerline 39 13/16″
• Crossbar centerline to finished floor 36 13/16″ (935 mm) at center
• Latch bolt height to finished floor 40 3/32″ (1018 mm) at center
• Lock stile case 8 1/4″ x 2 x 15/16″ (210 mm x 51 mm x 24 mm)
• Lock case 4 5/8″ x 5 3/4″ x 1 1/16″ (117 mm x 146 mm x 27 mm)
• Faceplate 1 1/4″ x 8″ x 7 /32″ (32 mm x 203 mm x 6 mm)
• Cylinder backset 2 3/4″ (70 mm)
• Hinge stile case 6″ x 1 3/4″ x 15/16″ (152 mm x 44 mm x 24 mm)
• Crossbar tubing 1″ (25 mm) outside diameter
• Projection Neutral – 4 7/8″ (124 mm) Depressed – 4″ (102 mm)
• Latchbolt Deadlocking – 3 /4″ (19mm) throw
• Fasteners and sex bolts (SBN) Includes screw pack for 1 3/4″ (44 mm) and 2 1/4″ (57 mm) thick metal or wood doors. Sex nuts and bolts included

Attributes

Manufacturer surcharge: 4.5%

Base Material: Brass

Commercial Residential: Commercial

Cylinder Type: 1-1/4″ Mortise

Device Length: 48″

Device Type: Mortise

Dogging Options: Hex Key Dogging

Door Height: 84″

Door Material: All Types

Door Thickness: 1-3/4″

Door Width: 3′ – 4′

Finish: 605/US3

Finish Family: Polished Brass

Fire Rated: No

Grade: Grade 1

Handing: Left Hand Reverse

Includes Cylinders: No

Includes Trim: No

Installation: Commercial

Limited Warranty: 3 Years

Mechanical Function: Classroom

Minimum Stile Size: 4-3/4″

Pack Qty: 1

Physical Appearance: Wide Stile Crossbar

Reversible: Yes

Series: 8875 Series Mortise Crossbar Devices

Strike Standard: 575

Subtype: Mortise Exit Devices

Trim Design: Lever with Escutcheon

Trim Type: Lever

Type: Exit Devices

Unit of Measure: Each

Resources

• 88 Series Rim Crossbar Devices;8875 Series Mortise Crossbar Devices Cut Sheet
• 8875/8875-F Wood Door Template
• E88K Series Wood Door Template
• E88TP Series Wood Door Template
• Von Duprin Finishes Chart
