Description

Sargent 56-8204 15 MELR Mortise Lock Body Only

Sargent 56-8204 15 MELR Mortise Lock Body Only is a Grade 1 storeroom or closet mortise lock designed with superior strength and durability in mind. This motorized electric latch retraction lock body features a conventional cylinder and is finished in satin nickel plating, ensuring both a sleek look and robust performance. Exceeding ANSI/BHMA A156.13 Series 1000 Grade 1 standards, the 8200 series sets the benchmark for mortise locks, providing maximum security and reliability. The Sargent 56-8204 is UL-cUL listed for three-hour fire doors, making it an ideal choice for various applications, including offices, hospitals, and educational institutions. Its thru-bolted lever trim and strengthened cylinder retainer enhance security, while the flexibility of 58 different functions ensures versatility to meet diverse needs. With six lever designs and 14 architectural finishes available, this lock allows for aesthetic customization that complements any environment. Installation and maintenance are simplified by its multifunctional lock body, reducing inventory requirements. Backed by a 10-year warranty, the Sargent 56-8204 Mortise Lock is engineered for long-lasting performance and peace of mind in high-traffic areas.

MELR Mortise Lock Body Only

Grade 1 Storeroom or Closet Mortise Lock Body Only, Motorized Electric Latch Retraction, Conventional Cylinder, ASA Strike, Satin Nickel Plated Clear Coated Finish

When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability

Constructed with the highest quality components to provide maximum security, durability and performance.

Considered the industry benchmark for all mortise locks on the market today, the robust lock is an attractive solution with a multitude of lever and escutcheon styles available.

Features:

• ANSI/BHMA Grade 2 certified for cycle and strength requirements
• UL-cUL listed for three-hour fire doors and windstorm applications
• Thru-bolted lever trim and strengthened cylinder retainer
• Available with security key systems (Degree, Signature, KESO, and XC)
• Available in 58 different functions, including electromechanical, security (freewheeling, security escutcheon, anti-vandal pull trim) and monitoring
• 6 lever designs, 2 roses/escutcheons designs, and 14 architectural finishes offered
• Available with behavioral health trim
• 10-year warranty
• Patented design and construction

Benefits:

• Strength & Reliability: Exceeds independent testing, making it the most durable mortise lock in the industry.
• Security: Security features provide resistance against unauthorized entry and vandalism.
• Flexibility & Aesthetics: Visual designwith a variety of functions, lever designs and architectural finishes match a wide range of styles and make it perfect for all types of applications (such as offices, hospitals, behavioral health environments, schools/universities).
• Ease of Installation & Maintenance: Multifunctional lockbody makes switching functions easy and reduces inventory requirements.

Attributes

Accessible: Yes

Ada Compliance: Yes

Ansi: A156.13/A156.25

Ansi Function: F07 – Storeroom/Exit

Application: Motorized Electric Latch Retraction

Baa Qualified: Yes

Bolt Projection: 3/4″ Latch

Commercial Residential: Commercial

Cylinder Type: Conventional Cylinder

Door Thickness: 1-3/4″

Finish: 619/US15

Finish Family: Matte Silver

Fire Rated: Up to 3 Hours

Fire Rating: Up to 3 Hours

Function: 04-Storeroom or Closet

Grade: Grade 1

Handing: Field Reversible

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Limited Warranty: 2 Years

Lock Face Size: 8″ x 1-1/4″

Of Keys: 2

Pack Qty: 1

Pins: 6

Screws: Combination

Series: 8200 Line Lever Mortise Locks

Std Keyway: LA

Std Latch Backset Dim: 2-3/4″

Std Latch Type: Dead Latch (Guarded)

Std Strike Height: 4-7/8″

Std Strike Number: 82-0110

Std Strike Type: ASA Strike

Std Strike Width: 1-1/4″

Subtype: Mortise Lock

Type: Locks, Cylinders, Cores, Keyblanks

Ul Listing: UL294/ULC60839-11-1

Unit of Measure: Each

Resources

• 7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructions
• 7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructions
• 7800/8200 Series Mortise Locks Installation Instructions
• 7900/8200 Series Mortise Locks Installation Instructions
• 8200 Line Lever Mortise Locks Cut Sheet
• 8200 Mortise Sectional Indicator Trim Template
• Sargent 8200 Series Environmental Product Declaration (EPD)
• Sargent 8200 Series Mortise Locks Sell Sheet
• Video: 8200 Series Mortise Lock Installation
