Marks Vestibule Lock – High Security Door Hardware

Description

Marks Hardware 175DA/26D Vestibule Lock Guide

Marks Hardware 175DA/26D Vestibule Lock offers a robust and reliable solution for commercial applications. This Grade 2 cylindrical lock features a vestibule function with a key in lever cylinder, ensuring efficient access control. Its 6-pin design enhances security, while the American Lever style adds a touch of sophistication. With a 3-1/4″ rose diameter and an ASA strike, installation becomes straightforward and compatible with various door configurations. Designed for durability, the Marks Survivor Series locksets are built to withstand the demands of high-traffic environments and come with a lifetime mechanical warranty. The satin chrome finish (626/US26D) not only provides a modern aesthetic but also ensures longevity against wear and tear. Fire-rated for up to 3 hours, this lock meets critical safety standards, including ADA compliance, making it suitable for a wide range of facilities. The non-handed design allows for easy installation on doors with a thickness of 1-5/8″ to 1-7/8″, accommodating diverse architectural requirements. Each lock is supplied with two cut keys and is keyed differently for added security. Whether for a commercial office, retail space, or institutional building, the Marks 175DA/26D Vestibule Lock exemplifies quality, functionality, and peace of mind.

Vestibule Lock

Grade 2 Cylindrical Lock, Vestibule Function, Key in Lever Cylinder, 6-Pin, American Lever, 3-1/4″ Rose Diameter, ASA Strike, 2-3/4″ Backset, Satin Chrome Finish, Non-Handed

Marks USA Survivor Series locksets are the most durable cylindrical lever locksets. The Survivor Series locksets are backed by Marks lifetime mechanical warranty. All functions are available in six standard finishes, are UL Listed for 3-hour fire rating, and satisfy ADA requirements.

Attributes

Accessible: Yes

Ada Compliance: Yes

Ansi: A156.2

Ansi Function: F88

Baa Qualified: Yes

Bolt Projection: 1/2″

Burglar Rated: No

Commercial Residential: Commercial

Country of origin: USA

Cylinder Type: Key in Lever Cylinder

Door Thickness: 1-5/8″ to 1-7/8″

Finish: 626/US26D

Finish Family: Matte Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: DA-Vestibule

Grade: Grade 2

Handing: Non-Handed

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Leverknob Design: 175 – American Lever

Limited Warranty: Lifetime

Lock Face Size: 1-1/8″ x 2-1/4″

Of Keys: 2

Origin: USA

Pack Qty: 1

Pins: 6

Restrictions: None

Roseescutcheon Design: 3-1/4″ Rose Diameter

Screws: Combination

Series: Marks Survivor Series Cylindrical Locksets

Std Keyway: Schlage C

Std Latch Backset Dim: 2-3/4″

Std Latch Number: 1134

Std Strike Number: 1145

Std Strike Type: ASA Strike

Subtype: Cylindrical Lock

Type: Locks, Cylinders, Cores, Keyblanks

Ul Listing: UL 10C

Unit of Measure: Each

Resources

• Marks Survivor Series Cylindrical Locksets Cut Sheet
