Marks Corridor Lock – Reliable Door Hardware for Secure Access

Description

Marks Hardware 195RT/26D Corridor Lock Guide

Marks Hardware 195RT/26D Corridor Lock is a Grade 1 cylindrical lock designed to provide exceptional security and durability for commercial applications. This lock features a corridor function with a key in lever cylinder, making it ideal for high-traffic areas where controlled access is necessary. With its robust 6-pin design and American lever style, this lock not only ensures reliability but also enhances the aesthetic appeal of any door. The 3-7/16″ rose diameter and 2-3/4″ backset provide a perfect fit for standard door installations, while the ASA curved lip strike ensures seamless operation. Finished in a sleek satin chrome, the 195RT/26D complements a variety of decor styles, making it a versatile choice for any commercial environment. This lock is UL Listed for a 3-hour fire rating, meeting stringent safety standards, and satisfies ADA compliance requirements, ensuring accessibility for all users. Backed by a lifetime mechanical warranty, you can trust the Marks Survivor Series for quality and performance. Suitable for doors with a thickness of 1-5/8″ to 1-7/8″, this non-handed lock is easy to install, making it a smart solution for your locking needs.

Corridor Lock

Grade 1 Cylindrical Lock, Corridor Function, Key in Lever Cylinder, 6-Pin, American Lever, 3-7/16″ Rose Diameter, ASA Curved Lip Strike, 2-3/4″ Backset, Satin Chrome Finish, Non-Handed

Marks USA Survivor Series locksets are the most durable cylindrical lever locksets. The Survivor Series locksets are backed by Marks lifetime mechanical warranty. All functions are available in six standard finishes, are UL Listed for 3-hour fire rating, and satisfy ADA requirements.

Attributes

Accessible: Yes

Ada Compliance: Yes

Ansi: A156.2

Ansi Function: F90

Baa Qualified: Yes

Bolt Projection: 9/16″

Burglar Rated: No

Category: Commercial Locks, Cylindrical Levers, Lock Sets

Commercial Residential: Commercial

Country of origin: USA

Cylinder Type: Key in Lever Cylinder

Door Thickness: 1-5/8″ to 1-7/8″

Finish: 626/US26D

Finish Family: Matte Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: T-Corridor

Grade: Grade 1

Handing: Non-Handed

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Leverknob Design: 195 – American Lever

Limited Warranty: Lifetime

Lock Face Size: 1-1/8″ x 2-1/4″

Of Keys: 2

Origin: USA

Pack Qty: 1

Pins: 6

Restrictions: None

Roseescutcheon Design: 3-7/16″ Rose Diameter

Screws: Combination

Series: Marks Survivor Series Cylindrical Locksets

Std Keyway: Schlage C

Std Latch Backset Dim: 2-3/4″

Std Latch Number: 1834

Std Strike Height: 4-7/8″

Std Strike Number: 1135

Std Strike Type: ASA Curved Lip Strike

Std Strike Width: 1-1/4″

Subtype: Cylindrical Lock

Type: Locks, Cylinders, Cores, Keyblanks

Ul Listing: UL 10C

Unit of Measure: Each

Resources

• Marks Survivor Series Cylindrical Locksets Cut Sheet
