KIT – SVR Surface Vertical Rod Exit Device – Grade 1 Stainless Steel

Description

PHI 2201 630 48 Precision Hardware Inc Exit Device

The Apex 2000 Series Touchbar Style Exit Device is highly regarded by architects and end-users alike. Many of the nationÍs largest healthcare and educational facilities prefer the Apex for itÍs aesthetic design and efficient engineering. All Apex 2000 Series Exit Devices are UL listed for panic and fire hardware and are certified to ANSI A156.3 Grade 1.

Attributes

Manufacturer surcharge: 7.0%

Alternate Codes: 2201-630-48, 220163048

Ansi: A156.3

Baa Qualified: Yes

Base Material: Stainless Steel

Category: Panic Devices, Panic Devices & Exit Alarms, SVR Panic Devices

Commercial Residential: Commercial

Country of Origin: Usa

Country of origin: USA

Device Length: 48 In.

Device Type: Surface Vertical Rod

Device Width: 42″

Dogging Options: Hex Key Dogging

Door Application: Panic Devices & Exit Alarms

Door Material: All Types

Door Thickness: 1-3/4″ to 2-1/4″

Door Width: 4′

Exit Device Category: Surface vertical rod

Finish: 630/US32D

Finish Code: 630

Finish Color: Satin Stainless Steel

Finish : Satin Stainless Steel

Finish Family: Matte Silver

Fire Rated: No

Function: Exit Only

Grade: Grade 1

Handing: Field Reversible

Includes Trim: No

Installation: Commercial

Limited Warranty: 5 Years

Mechanical Function: Exit Only

Minimum Stile Size: 4-1/4″

Origin: USA

Pack Qty: 1

Physical Appearance: Wide Stile Pushpad

Reversible: Yes

Series: 3R0

Strike Bottom: S460

Subtype: Exit Device

Top Strike: S300

Type: Exit Devices

Ul Listing: UL10C

Unit of Measure: Each
