KIT – Classroom Exit Trim with Key Locks and Escutcheon L Lever

Description

Sargent 713-ETL-BSP RHR LESS CYLINDER Classroom Exit Trim Kit, Key Lock, RHR, BSP Black Suede, Less Mortise Cylinder

Sargent 713-ETL-BSP RHR LESS CYLINDER KIT offers a robust solution for classroom exit trim needs, combining security with ease of use. Designed for right-hand reverse applications, this trim features a sleek escutcheon with a lever handle, enabling smooth one-handed operation. The kit is engineered to work seamlessly with a variety of exit devices, including the 8313, 8713, 8913, 9713, 9813, and 9913 models. Constructed with durability in mind, this trim is non-handed and through-bolted to the chassis, enhancing security in high-traffic areas. The Sargent 713-ETL-BSP is compatible with a range of functions, including key locking and unlocking capabilities, allowing for tailored security options based on your specific needs. The easy-to-operate lever handle ensures that it meets the demands of everyday use. Finished in a sophisticated Black Suede Powder Coat (BSP), this trim not only provides a modern aesthetic but also stands up to the rigors of daily wear. With various functions available, from night latch to electrified options, the Sargent 713-ETL-BSP is a versatile choice for panic devices and exit alarms, making it an ideal addition to any security-conscious environment.

KIT – Classroom Exit Trim (Key Locks/Unlocks Exit Trim), Less 41 Mortise Cylinder, Escutcheon with L Lever, RHR Right Hand Reverse, BSP Black Suede Powder Coat (Works with (12) 8313, 8713, 8913, 9713, 9813 and 9913)

Notice: The info below is not item specific.

The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.

Features:

• ANSI/BHMA Finishes
• Easy operating lever handle allows convenient one hand operation
• ET trim is not available in 32 or 32D
• Stainless steel levers are available

Functions:

• 04: Night latch key retracts latch #34 cylinder supplied. ANSI 03
• 10: No O/S operation or cylinder (pull only). ANSI 02
• 13: Key outside unlocks/locks trim #41 cylinder supplied. ANSI 08
• 15: Passage only (no cylinder). ANSI 14
• 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
• 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 & I/S #44. ANSI 07
• 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
• 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
• 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
• 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied

Finishes:

• 0-3/605 – Bright brass, clear coated
• 0-4/606 – Satin brass, clear coated
• 0-9/611 – Bright bronze, clear coated
• 1-0/612 – Satin bronze, clear coated
• 10B/613 – Dark oxidized satin bronze, oil rubbed
• 10BE/613E – Dark oxidized satin bronze, equivalent
• 10BL/613L – Dark oxidized satin bronze clear coated
• 20D/624 – Dark statuary bronze lacquered
• 2-6/625 – Bright chrome plated
• 26D/626 – Satin chrome plated
• 3-2/629 – Bright stainless steel
• 32D/630 – Satin stainless steel
• BSP – Black suede powder coat
• WSP – White suede powder coat

Attributes

Alternate Codes: 713-ETL-BSP RHR LESS CYLINDER, 713ETLBSPRHRLESSCYLINDER

Category: Panic Devices & Exit Alarms, Panic Device Trims

Cylinder Type: Less Cylinder

Door Application: Panic Devices & Exit Alarms

Finish Code: BSP

Finish Color: Black Suede Powder Coat

Handing: Right Handed Reverse
