Kaba Access MultiHousing Mortise Lock – Advanced Electric Locking Solution

Description

Dormakaba 79T1011KF30-626 MultiHousing Mortise Lock Instructions

Kaba Access Dormakaba 79T1011KF30-626 MultiHousing Mortise Lock is a Grade 1 heavy-duty electronic mortise lockset designed to enhance security and convenience in multi-housing applications. This robust lock features a clutch mechanism and a built-in contactless RFID reader, allowing for seamless access control without the need for traditional keys. The toggle mode lock and concealed key override provide flexibility, ensuring that you maintain access when needed. The lock is designed for doors with a thickness ranging from 1-3/8 inches to 2-1/2 inches and boasts a long lever design for ease of use. Its satin chrome finish (626/US26D) not only adds an elegant touch but also ensures durability. The 79T1011KF30 is field reversible, accommodating various door handing requirements. With a battery life of up to three years powered by three AA batteries, this lock is both reliable and low-maintenance. It features a bolt projection of 1 inch and a latch backset dimension of 2-3/4 inches. Additionally, it is fire-rated, making it a safe choice for a variety of environments. Backed by a limited two-year warranty, this electronic mortise lock is a practical choice for building professionals and discerning homeowners alike.

MultiHousing Mortise Lock

Grade 1 Heavy Duty Electronic Mortise Lockset with Clutch Mechanism, Built-in Contactless RFID Reader, Toggle Mode Lock, Concealed Key Override, Long Lever, Field Reversible, Standard No BLE, Satin Chrome

Attributes

Manufacturer surcharge: 7.0%

Battery Life: 3 Years

Bolt Projection: 1 In.

Cylinder Type: Conventional Cylinder

Door Thickness: 1-3/8 In. to 2-1/2 In.

Finish: 626/US26D

Fire Rated: Yes {Variable}

Fire Rating: Yes {Variable}

Grade: Grade 1

Handing: Field Reversible

Keying: Keyed Alike

Latch Backset Dim: 2-3/4 In.

Leverknob Design: Long

Limited Warranty: 2 Years

Pack Qty: 1

Power: 3 AA Batteries

Series: 79 Series Electric Locks

Ship Weight: 8.5 lbs.

Subtype: Electric Mortise Lock

Type: Electric Locks

Unit of Measure: Each

Resources

• Door Preparation Drawing for Power-Plex 2000 & E-Plex 7900 Seriers
