Description
Dormakaba RM12E0G-26D Insync Mortise Lock Instructions
Kaba Access Dormakaba RM12E0G-26D InSync Mortise Lock combines advanced functionality with modern design, making it an ideal choice for both residential and commercial applications. This battery-operated lock features an auto deadbolt and is designed for left-hand installations, finished in a sleek satin chrome (626/US26D) that complements contemporary architecture. The InSync system works seamlessly with SAM RF software, allowing for streamlined management of key and access control across various entry points, including utility doors and apartment entrances. With a single key required for multiple access points, users enjoy a convenient “No Touring” experience. Administrators can program the locks just once, and the software will automatically update each lock with essential information, such as access privileges and tenant changes. This electric mortise lock accommodates door thicknesses from 1-3/8 inches to 2 inches and features a bolt projection of 1 inch. The Gala lever design adds a touch of elegance, while the lock’s fire-rated capabilities ensure safety without compromising aesthetics. Powered by 4 AA batteries and backed by a one-year limited warranty, the Dormakaba RM12E0G-26D is a reliable choice for modern access control needs.
Insync Mortise Lock
InSync Battery Operated ASM Mortise Lock, Auto Deadbolt, Entry, Gala Lever, Left Hand, Satin Chrome
InSync locks work together with SAM RF software to create a single system that manages both key and access control at perimeter entries. These multihousing locks are developed to make access convenient.
InSync locks work together with SAM RF software to create a single system that manages both key and access control at perimeter entries, amenity and utility doors as well as apartment or bedroom doors. With the InSync system, administrators only need to program the locks once; the software continually manages critical informational changes such as access privileges and move ins/outs. This information is delivered automatically to each lock via the InSync key once the “New” version of the key is created and used in the locks. Only one key is required for use at multiple access points, creating a convenient and efficient “No Touring”user experience. InSync lock models accommodate virtually all door types and preparations, and common area/amenity applications. The locks feature contemporary finishes and lever options to complement today’s design trends.
Attributes
Manufacturer surcharge: 7.0%
Bolt Projection: 1 In.
Door Thickness: 1-3/8 In. to 2 In.
Finish: 626/US26D
Fire Rated: Yes {Variable}
Fire Rating: Yes {Variable}
Handing: Left Hand
Latch Backset Dim: 2-3/4 In.
Leverknob Design: G – Gala Lever
Limited Warranty: 1 Year
Pack Qty: 1
Power: 4 AA Batteries
Series: InSync Electric Locks
Ship Weight: 10 lbs.
Std Strike Height: 4-7/8 In.
Std Strike Width: 1-1/4 In.
Subtype: Electric Mortise Lock
Type: Electric Locks
Unit of Measure: Each
Resources
- InSync C Data Sheet
- InSync C Panic/Exit Device Template
- InSync CL Lock Usage Instructions
- InSync CL/SL Installation Instructions
- InSync CM/SM Installation Instructions
- InSync CP Installation Instructions
- InSync CR Installation Instructions
- InSync Cylindrical Deadbolt Adjustment Installation Instructions
- InSync Cylindrical Latch Template
- InSync D Data Sheet
- InSync D Installation Instructions
- InSync Deadbolt Template
- InSync I Data Sheet
- InSync I Installation Instructions
- InSync Interconnect Template
- InSync L Installation Instructions
- InSync L Lock Usage Instructions
- InSync Lock Series SAM RF Software Data Sheet
- InSync M Data Sheet
- InSync M Installation Instructions
- InSync M Lock Usage Instructions
- InSync Mortise 1.25 Template
- InSync Mortise Narrow Template
