Heavy Duty Track Closer AL by LCN – Durable Surface Door Closer

Description

LCN 4013T-DE LH 689 Heavy-Duty Track Closer AL

LCN 4013T-DE LH 689 Heavy Duty Track Closer AL is engineered for exceptional performance in high-traffic environments, making it an ideal choice for institutional applications. This double egress track door closer is designed specifically for left-handed installations, ensuring functionality and durability where it matters most. Hailing from the reliable 4010T Series, this heavy-duty closer meets the rigorous demands of constant use, with a UL and cUL listing and compliance with ANSI/BHMA Grade 1 standards. Its robust design accommodates interior doors up to 5’0″ and exterior doors up to 4’0″, while the non-sized 4011 cylinder is adjustable for varied door heights. The LCN Green Dial spring force indicator simplifies adjustment, taking the guesswork out of installation. Constructed with a full plastic cover, the closer is available in a matte silver finish, with optional plated finishes for a customized look. It features a hydraulic mounting style on the pull side, accommodating a 100-degree swing for versatile usage. With a generous 30-year limited warranty, the LCN 4013T-DE ensures reliability and performance, making it a preferred choice for commercial installations. Experience quality and peace of mind with this dependable door closer.

Heavy Duty Track Closer AL

Double Egress Track Door Closer, Left Hand, Aluminum

The 4010T is LCN’s best performing heavy duty surface track door closer designed for institutional and other high traffic applications.

The 4010T is LCN’s best performing heavy duty closer designed specifically for institutional and other rugged high traffic applications.

The 4010, 4020 and 4110 Series are heavy-duty closers that meet demands for high-traffic installations and each are designed specifically for unique mounting applications. They are UL and cUL listed, meet ANSI/BHMA Grade 1 standards and boast 30-year warranties. They feature a standard plastic cover, with optional plated finishes for the cover, arm and fasteners. They also feature the LCN Green Dial spring force indicator, which takes the guesswork out of adjustment.

• The 4010Series mounts hinge pull side.
• Sized cylinders for interior doors to 5’0” and exterior doors to 4’0”.
• Non-sized cylinder (4011) adjustable for interior doors to 4’6” and exterior doors to 3’6”.
• Closer mounts hinge side, specify right or left swinging door.
• Corner brackets available. See Options tab for options.
• 4011 cylinder meets ADA requirements.
• Standard or optional custom powder coat finish.
• Optional plated finish on metal cover, arm and fasteners.
• Optional SRI primer for installations in corrosive conditions is available with powder coat only.
• The 4010 Series is UL and cUL listed with regular or fusible link arms for self-closing doors.
• Tested and certified under ANSI Standard A156.4, Grade 1.

Attributes

Manufacturer surcharge: 4.5%

Arm Type: Slide Track Arm, Double Egress

Baa Qualified: Yes

Base Material: Varies

Cold Weather Fluid: Yes

Commercial Residential: Commercial

Cover: Full Plastic

Degree Swing: 100 Deg.

Finish: 689/US28

Finish Family: Matte Silver

Grade: Grade 1

Handing: Left-Handed

Hold Open: No

Installation: Commercial

Limited Warranty: 30 Years

Mounting Group: Hydraulic

Mounting Location: Pull Side

Mounting Style: Regular

Pack Qty: 1

Series: 4010T Series Surface Mounted Closers

Ship Weight: 16 lbs.

Subtype: Surface Closers

Type: Surface

Unit of Measure: Each

Resources

• 4010T Series Surface Mounted Closers Cut Sheet
• LCN 4000 Series Catalog
• LCN 4010 Series Cut Sheet
• LCN 4010, 4010T, 4510, 4510T Drop Plate Installation Instructions
• LCN 4010T Installation Instructions
• LCN Closers & Auto Operators Installation Guide
• LCN Closers & Automatic Operators Parts Manual
• Von Duprin Finishes Chart
