Description
Hafele 290.11.055 Z-Clip Rail
Hafele 290.11.055 Rail, Z-Clip offers a robust and efficient solution for securely mounting wall panels. Crafted from durable aluminum, this 144-inch long rail features a convenient 3/8″ lift-off design, facilitating easy installation and removal of panels when necessary. The rail’s width of 1 3/8″ and a height of 1/4″ make it an unobtrusive choice for various applications, ensuring your panels maintain a sleek profile. The installation process is straightforward: mount the clips on the back side of the panel and affix the rails horizontally onto the wall surface, fastening them at stud locations. This method not only provides a secure connection through the interlocking profiles of the clips and rails but also conceals the mounted fittings for a clean finish. With holes positioned 8 inches on center, alignment becomes effortless, enhancing the overall efficiency of the installation. For added convenience, the mounting clips are designed to be used with #8 pan head screws, ensuring a reliable hold. The Hafele 290.11.055 Rail, Z-Clip is perfect for professionals and knowledgeable homeowners seeking an economical and effective mounting solution for wall panels. With shipping via UPS, it’s easily accessible for your next project.
Rail, Z-Clip
Aluminum, 3/8″ Lift-off, 144″ width, with holes 8″ on center
Panel clips offer an easy and economical solution for installation of wall panels: Mount clips on the back side of panel, mount rails horizontally on wall surface and fasten at stud locations, or hang panel on wall rail. Interlocking profile of clips and rails provide a secure connection Mounted fittings are concealed Mount clips with #8 pan head screws
Attributes
Height (inch): 1/4″
Length (inch): 144″
Material: Aluminum
Version: 3/8″ Lift-off
Width (inch): 1 3/8″
Resources
- Monarch Clip 3-Part CSI Specification
- Monarch Z Clip FAQ
- TCH_Furniture_Cabinetry_Hardware_ 2022 | Page 11.74A
- Technical data sheet
- Technical data sheet
- The Monarch Z Clip
