Hafele Hawa Junior 40/B Sliding Door Hardware Set

Description

Hafele 940.41.007 Hawa Junior 40/B Sliding Door Hardware Set

Hafele 940.41.007 Sliding Door Hardware, Hawa Junior 40/B, set offers a sophisticated solution for 1-leaf wooden sliding doors, seamlessly combining functionality with ease of installation. This system supports door weights up to 40 kg and features a height adjustment facility of -3 to 3 mm, ensuring a perfect fit in any space. With a minimum installation height and a design that includes a track buffer and a wall buffer, it promotes smooth, quiet operation that enhances the user experience. Designed for versatility, this hardware is suitable for both wall pocket installations and ceiling or wall mounting options. It accommodates doors with a thickness of 35–80 mm and a maximum height of 4,000 mm. The maximum door width for pocket door solutions is capped at 1,250 mm, making it ideal for a variety of applications.Moreover, the system allows for subsequent disassembly of the running track without wall damage, maintaining accessibility for maintenance. Certified in compliance with EN 1527:2013, this durable hardware ensures reliability and long-lasting performance. Whether you’re upgrading a residential space or working on a commercial project, the Hafele Hawa Junior 40/B set is an excellent choice for contemporary sliding door solutions.

Sliding Door Hardware, Hawa Junior 40/B, set

for 1-leaf wooden sliding doors, height adjustable, min. installation height, for door weight up to 40 kg, With 1 track buffer/1 wall buffer

Smooth quiet operation Outstanding durability Rattle-free bottom guide Minimum installation height Suspension with carrier profile
For 2 bi-parting sliding doors, please order 2 sets

Attributes

Adjustment facility: Height adjustment facility: -3 – 3 mm, with integrated anti-twist protection, Track buffer with adjustable retaining spring

Area of application: For 1 and 2 sliding wood doors For 1-leaf sliding doors for wall pocket installation

Classification in compliance with EN 1527: -|6|1|-|1|0|-|1|3

Controller installation options: Ceiling installation, Wall mounting, Integrated ceiling installation, Wall pocket solution

Door processing: With recess

For door height: ≤4,000 mm

For door material: wood

For door thickness: 35 – 80 mm

For door thickness min.: 1″

For door weight: ≤40 kg

For door width: ≤3,000 mm

Functionality: subsequent disassembly of the running track without opening the wall is possible, the running gear and the soft and self closing mechanism can be removed, stopper position can be readjusted in wall pocket

Installation: Suspension with recessed support profile

Installation reference: Pocket door solution: subsequent disassembly of the running track is possible without opening the wall, running gear and soft and self closing mechanism can be removed, Stopper position in the wall pocket , readjustable

Load bearing capacity: 88 lbs.

Max. door weight: 88.00 lb

Model: 40 B

Note on door width: The max. door width for the pocket door solution is 1,250 mm.

Number of doors: 1.00

Number of doors per system max.: 1 to 2

Order reference: Order 2 sets for 2-leaf sliding doors.

Running position: Top

Soft closing mechanism: with track buffer on one side, with wall buffer on one side

Standard: Certified in compliance with EN 1527:2013

Version: with track buffer on one side, with wall buffer on one side

Resources

• Installation instructions
• Manufacturer information
• TCH_Architectural_Hardware_ 2022 | Page 1.79
• TCH_Architectural_Hardware_ 2022 | Page 1.81
