Description
Sargent 2870-65G04 KB 26D Grade 2 Storeroom Lock
Sargent 2870-65G04 KB 26D Grade 2 Storeroom Lock offers robust security and versatility for medium-duty applications. This Grade 2 storeroom/closet cylindrical lock features a sleek satin chrome finish and a non-handed B lever design, making it suitable for a variety of door configurations. Engineered to exceed ANSI A156.2 Series 4000 Grade 2 standards, this lock is windstorm certified, ensuring reliability in demanding environments. Designed for doors ranging from 1-3/8″ to 1-3/4″ thick, the Sargent 2870 includes a standard 2-3/4″ backset, though 2-3/8″ is available upon request. The cylindrical housing is constructed from steel with a zinc dichromate finish, while the front is made from durable wrought brass and stainless steel. A 6-pin brass cylinder with LA keyway enhances security, and the lock includes two nickel silver keys. The included 600 curved lip strike is available in brass or stainless steel, providing reliable performance. With a minimum stile width of 4-1/2″ and a 10-year limited warranty, this lock is an excellent choice for commercial applications where durability and functionality are paramount. Experience peace of mind with the Sargent 2870-65G04, designed for long-lasting use and dependable security.
Grade 2 Storeroom Lock
Grade 2 Storeroom/Closet Cylindrical Lock, B Lever, SFIC Disposable Construction Core, Satin Chrome Finish, Non-handed
The SARGENT 6500 Line is a standard duty key-in-lever lock designed to exceed the requirements of ANSI A156.2 Series 4000 Grade 2.
Windstorm certified and has several function options.
- For Doors: 1-3/8″ (35mm) to 1-3/4″ (44mm) only
- Backset: 2-3/4″ (70mm) standard; 2-3/8″ (60mm) optional (20- Prefix)
- Cylindrical Housing: Steel zinc dichromate finish
- Front: Wrought brass and stainless steel;
- 2-1/4″ (57mm) x 1-1/8″(29mm)
- Strike:600 Curved Lip, Brass or Stainless Steel Standard,808 ANSI Curved Lip available (28- prefix),505 Full Lip strike available (14- prefix)
- Hand: Universal, not handed
- Latch: Brass 1/2″ (13mm) throw
- Keys: Two, nickel silver
- Cylinder: Brass, 6 pin, LA keyway standard
- Finishes : 3, 4, 10, 10B, 26, 26D
- (No Split Finish)
- Door Prep: ANSI A115.2 (161) Modified
- Minimum Stile: 4-1/2″ (114mm)
Attributes
Ansi: F86
Ansi Function: F86 – Storeroom
Application: Medium Duty Cylindrical
Base Material: Brass, Bronze
Bolt Projection: 1/2″
Bore Hole Diameter: 2-1/8″
Box Depth Fraction: 8-1/4″
Box Height Fraction: 4-1/4″
Box Width Fraction: 7-1/8″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: United States
Cylinder Type: SFIC Disposable Construction Core
Cylinders Present: Single Cylinder
Door Thickness: 1-3/8″ to 1-3/4″
Dust Box: None
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 04-Storeroom or Closet
Function Family: Storeroom
Grade: Grade 2
Handing: Non-handed
Installation: Commercial
Latch Bore Diameter: 1″
Lever Knob: Lever
Lever Knob Design Name: B
Leverknob Design: B Lever
Leverknob Design Family: Curved Lever
Limited Warranty: 10 Year Warranty
Lock Face Size: 1-1/8″ x 2-1/4″
Manufacturer Function: Storeroom/Closet
Maximum Door Thickness: 1-3/4″
Minimum Door Thickness: 1-3/8″
Origin: United States
Pack Height: 4.25″
Pack Height 2: 9″
Pack Length: 8.25″
Pack Length 2: 20.75″
Pack Qty: 1
Pack Volume: 249.82 in³
Pack Volume 2: 2801.25 in³
Pack Width: 7.13″
Pack Width 2: 15″
Pins: 6
Product Height: 4.25″
Product Length: 8.25″
Product Width: 7.13″
Projection: 2-3/8″
Rose Escutcheon: Rose
Roseescutcheon Design: 3-3/8″ Rose Diameter
Roseescutcheon Dimensions: 3-3/8″
Screws: Wood/Machine Screws
Series: 6500-Line Bored Lever Locks
Ship Weight: 4.2 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 103121
Std Latch Type: Deadlatch
Std Strike Height: 4-7/8″
Std Strike Number: 808
Std Strike Type: ANSI Curved Lip Strike
Std Strike Width: 1-1/4″
Strike Dimensions: 1-1/4″ x 4-7/8″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: ANSI A156.2, Series 4000, Grade 2, UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 10
Resources
- 6500 Line (All Functions and Prefixes) Template
- 6500 Line Single & Double Lever Pull Installation Instructions
- 6500-Line Bored Lever Locks Cut Sheet
- 800 Strike Template
- 808 Strike for ANSI A115.2 – 28 Prefix Template
- Hurricane Resistant Bored Locks Sell Sheet
- Removal & Insertion of Sargent Plastic Construction Plugs for 6500 Installation Instructions
- Sargent Bored Lock Brochure
