Grade 2 Storeroom Lock by Hager – Durable Door Hardware

Description

Hager 3580AUG26D August Lever Storeroom Cylindrical Lock Satin Chrome Finish

Hager 3580AUG26D August Lever Storeroom Cylindrical Lock Satin Chrome Finish

• Grade 2 Storeroom Lockset With August Lever
• Standard Duty Commercial
• No Exposed Mounting Screws
• Non-Handed
• Zinc Based Lever

Attributes

Manufacturer surcharge: 8.75%

Ansi Function: F86 – Storeroom

Baa Qualified: No

Backset: 2-3/4″

Bolt Projection: 1/2″ Latch

Burglar Rated: No

Commercial Residential: Commercial

Country of Origin: Taiwan

Country of origin: Taiwan

Cylinder Type: 6-Pin

Design: August Lever

Dust Box: None

Finish: Satin Chrome

Finish : Satin Chrome

Finish Family: Matte Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 80-Storeroom

Grade: Grade 2

Handing: Non-Handed

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Leverknob Design: AUG – August Lever

Leverknob Design Family: Straight Lever

Limited Warranty: Lifetime

Of Keys: 2

Origin: Taiwan

Pack Qty: 1

Pins: 6

Restrictions: None

Rose Escutcheon Dimensions Inside: 3-17/32″ Diameter Rose

Screws: Combination

Series: Hager 3500 Series

Std Keyway: Schlage C Keyway

Std Latch Backset Dim: 2-3/4″

Std Latch Type: Dead Latch (Guarded)

Std Strike Height: 4-7/8″

Std Strike Number: 3935

Std Strike Type: ASA

Std Strike Width: 1-1/4″

Strike: ASA Strike

Subtype: Cylindrical

Type: Mechanical Commercial Locksets

Unit of Measure: Each

Resources

• 3417 & 3517 Dummy Knob Instruction Sheet
• 3500 Series ANSI Grade 2 Knob Set Instruction Sheet
• 3500 Series ANSI Grade 2 Lever Set Instruction Sheet
• 3500 Series Grade 2 Cylindrical Locks Cut Sheet
• 3517 Rev 1 Dummy Instruction Sheet
• Hager Locks Catalog
• Timing Lever Set Instruction Sheet
