Grade 2 nexTouch Deadbolt by Yale – Electronic Security Solution

Description

Yale NTD643-ACC BSP Grade 2 nexTouch Deadbolt

Yale NTD643-ACC BSP Grade 2 NexTouch Deadbolt delivers a robust and modern solution for your security needs. Designed for commercial use, this Grade 2 deadbolt features a sleek black suede powder coat finish, ensuring it not only looks great but also withstands the rigors of daily use. The non-keyed system with no deadbolt cylinder override offers a streamlined experience, while the field-reversible handing allows for easy installation in various door configurations. Ideal for multi-family properties, small businesses, retail spaces, and more, the NexTouch deadbolt boasts ANSI/BHMA Grade 1 certification, guaranteeing long-lasting performance. With a fully modular design, it enables users to upgrade to advanced security technologies such as Data-on-Card or ZigBee/ZWave wireless options as needs evolve.This keypad lock supports up to 100 user codes, making it perfect for high-traffic environments. Power backup ensures you won’t face lockouts due to battery failure, while the capacitive touchscreen provides a user-friendly interface. The deadbolt not only enhances security but also simplifies access control, reducing maintenance costs and improving operational efficiency.With a limited three-year warranty and fire ratings up to 90 minutes when paired with the AYRD-FKIT Fire Kit, the Yale NTD643-ACC is a reliable choice for your security solutions.

Grade 2 nexTouch Deadbolt

Grade 2 NexTouch Generation 3 Deadbolts and Deadlatches With Accentra, No Deadbolt Without Cylinder Override, Non-Keyed, Black Suede Powder Coat Finish, Field Reversible

Unlock what’s next in security with NexTouch commercial keypad door locks from Yale. The NexTouch keyless electronic door lock combines a modern look with durability that is perfect for your multi-family property, small business office space, retail storefront, hotel, airport, restroom, or mixed-use commercial building. With a heavy-duty design and ANSI/BHMA Grade 1 certification, NexTouch keypad locks provide durable and reliable security from Yale Door Locks – a trusted brand for over 170 years.

ANSI/BHMA Grade 1 Certified Keypad Lock

The fully modular design of NexTouch allows users to easily upgrade to more advanced security technologies as their requirements grow and change. Features solutions for standalone, multi-family and small business applications.

Ideal for: Management offices,restrooms,staff lounges,access to airport apron,storage closets,new construction or renovation projects of multi-family facilities with individual units and common areas,small to medium-sized businesses with new or existing automation systems.

Benefits:

• Easy Traffic Control: Engineered to provide a comprehensive, easy-to-use access control solution to protect your facility and personnel
• Modular Technology: Unique and versatile design enables upgrade of the lock’s technology when needed
• Key-free Convenience: Reduces investment and maintenance costs
• Strong and Reliable: ANSI/BHMA Grade 1 certification ensures long life and reliability

Features:

• Modular technology allows users to upgrade to Data-on-Card or ZigBee/ZWave wireless technologies as system requirements change and grow
• Capacitive touchscreen or pushbutton keypad available, for tactile environments and ADA compliance
• Privacy mode enabled by a button push
• Up to 100 user codes in keypad only operation
• 9V battery power backup prevents lockout even if the batteries fail

Attributes

Access Function: Software Programmable

Accessible: No

Ada Compliance: No

Ansi: ANSI/BHMA A156.36, Grade 2

Application: Capacitive Touchscreen

Baa Qualified: Yes

Base Series: NexTouch

Bore Hole Diameter: 2-1/8″

Commercial Residential: Commercial

Cylinder Type: Non-Keyed

Door Thickness: 1-3/8″ to 2-1/4″

Finish: BSP

Finish Family: Black

Fire Rated: Yes

Fire Rating: 90 Minutes with AYRD-FKIT Fire Kit

Function: No Deadbolt Without Cylinder Override

Grade: Grade 2

Handing: Field Reversible

Installation: Commercial

Keypad Type: Capacitive Touchscreen

Latch Backset Dim: 2-3/8″ or 2-3/4″

Latch Backset Dimension: 2-3/4″

Latch Bore Diameter: 1″

Limited Warranty: 3 Years

Operating Voltage: 4 AA Batteries

Pack Qty: 1

Power: Battery Pack

Reader Technology: Keypad and Accentra

Series: Yale NexTouch Stand-Alone Lock

Series Name: NexTouch (Generation 3)

Software: Accentra

Std Latch Type: Deadbolt

Std Strike Height: 2-1/4″

Std Strike Type: T-Radius Strike

Std Strike Width: 1″

Subtype: Deadbolts and Deadlatches

Type: Integrated and Pushbutton

Ul Listing: UL Listed with AYRD-FKIT Fire Kit

Unit of Measure: Each

Users: 25

Wireless: Yes
