Grade 2 Bed/Bath Privacy Lock by Schlage – Secure & Stylish

Description

Schlage S40D JUP 605X625 Grade 2 Bed/Bath Privacy Lock Instructions

Schlage S40D JUP 605X625 Grade 2 Bed/Bath Privacy Lock offers a perfect blend of style and security for both commercial and residential applications. Designed with a privacy function, this non-keyed tubular lock features the elegant Jupiter lever, providing a sophisticated touch to any door. The lock is available in a striking bright brass exterior and a sleek bright chrome interior finish, ensuring it complements a variety of décor styles. With a Grade 2 rating, this lock meets ANSI A156.2 standards, making it a reliable choice for high-traffic areas such as bathrooms and bedrooms. Its non-handed design allows for easy installation on doors ranging from 1-3/8″ to 1-7/8″ thick. The dead latch mechanism ensures a secure fit, while the 2-1/2″ projection guarantees durability.Engineered for longevity, the Schlage S40D is backed by a 3-year limited warranty and complies with ADA accessibility standards, making it an ideal solution for public buildings. With an easy-to-maintain plastic dust box and UL/cUL listing, this lock not only enhances safety but also simplifies repair and upkeep. Choose Schlage for dependable security that stands the test of time.

Grade 2 Bed/Bath Privacy Lock

Grade 2 Tubular Lock, Privacy Function, Non-Keyed, Jupiter Lever, Bright Brass Exterior and Bright Chrome Interior Finish, Non-handed

For more than 90 years, Schlage has been creating the strongest and most technologically advanced security products for schools, hospitals, hotels, commercial and institutional buildings, multi-family properties and homes.From durable mechanical locks to comprehensive electronic access control solutions and biometrics, Schlage provides protection at critical moments – when property and personal security are at stake. With a wide range of products, styles and finishes, Schlage has products for the most demanding project specifications.In public buildings, in the workplace, and in homes, at the end of the day Schlage stands for one thing: strong. When you choose a Schlage lock, you can be sure you’ve done the job right, the first time. After all, our products are among the most durable and dependable on the market today. Our locks are easy to install, and simple to repair and maintain. That means fewer callbacks for you and total safety and security for your customers.

Attributes

Manufacturer surcharge: 4.5%

Accessible: Yes

Ada Compliance: Yes

Ansi: ANSI A156.2, Series 4000, Grade 2

Ansi Function: F76 – Privacy

Baa Qualified: Yes

Bolt Projection: 1/2″

Bore Hole Diameter: 2-1/8″

Box Depth Fraction: 9-1/2″

Box Height Fraction: 4-3/4″

Box Width Fraction: 8-1/4″

Burglar Rated: No

Commercial Residential: Commercial

Country of origin: Mexico

Cylinder Type: Non-Keyed

Cylinders Present: Non-Keyed

Door Thickness: 1-3/8″ to 1-7/8″

Dust Box: Plastic

Finish: 605/US3

Finish B: 625/US26

Finish Family: Split Finish

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 40-Privacy

Function Family: Privacy

Grade: Grade 2

Handing: Non-handed

Installation: Commercial

Latch Bore Diameter: 7/8″

Lever Knob: Lever

Lever Knob Design Name: Jupiter

Leverknob Design: JUP – Jupiter Lever

Leverknob Design Family: Curved Lever

Limited Warranty: 3 Years

Lock Face Size: 1″ x 2-1/4″

Manufacturer Function: Bath/Bedroom Privacy Lock

Maximum Door Thickness: 1-7/8″

Minimum Door Thickness: 1-3/8″

Origin: Mexico

Pack Height: 4.75″

Pack Length: 9.5″

Pack Qty: 1

Pack Volume: 372.28 in³

Pack Width: 8.25″

Projection: 2-1/2″

Restrictions: None

Rose Escutcheon: Rose

Roseescutcheon Design: 2-1/2″ Rose Diameter

Roseescutcheon Dimensions: 2-9/16″

Screws: Combination

Series: S Series Tubular Lever Locks

Ship Weight: 5 lbs.

Std Latch Backset Dim: 2-3/8″ – 2-3/4″

Std Latch Number: 16-203

Std Latch Type: Dead Latch (Guarded)

Std Strike Height: 2-3/4″

Std Strike Number: 10-001

Std Strike Type: T-Standard Strike

Std Strike Width: 1-1/8″

Strike Dimensions: 1-1/8″ x 2-3/4″

Subtype: Tubular Lock

Type: Locks, Cylinders, Cores, Keyblanks

Ul Listing: UL/cUL

Unit of Measure: Each

Resources

• 10-001, 10-013, 10-016, 10-019 Strikes, Metal Template
• 10-001, 10-013, 10-016, 10-019 Strikes, Wood Template
• 10-025, 10-072, 10-087 Strikes, Metal Door Jamb Template
• 10-025, 10-072, 10-087 Strikes, Wood Door Jamb Template
• 10-027 Strike, Wood Door Jamb Template
• S Series Installation Guide
• S Series Tubular Lever Locks Cut Sheet
• Von Duprin Finishes Chart
