Description
Schlage ND80JD-MED ATH 626 Grade 1 Storeroom Lock
Schlage ND80JD-MED ATH 626 Grade 1 Storeroom Lock offers robust security and reliability for commercial applications. Designed with the Athens lever, this Grade 1 storeroom lock features a satin chrome finish that not only enhances aesthetics but also provides durability. The lock is Medeco LFIC prep less core, allowing for flexible keying options tailored to your needs. Built to withstand over three million operating cycles, the ND Series ensures longevity and dependability, making it ideal for high-traffic environments such as healthcare, education, and government facilities. Its non-handed design simplifies installation, accommodating door thicknesses from 1 5/8″ to 2 1/8″. The lock features a 1/2″ throw deadlocking latch bolt and is constructed with a zinc-plated chassis for corrosion resistance, ensuring reliable performance. With ANSI A156.2 Series 4000 Grade 1 certification, the Schlage ND80JD-MED exceeds industry standards for cycle, hammer blow, and lever pull tests. Additionally, the lock comes with a ten-year limited warranty, giving you peace of mind. Whether you are securing a storeroom or other critical access points, this lock combines strength, functionality, and style.
Grade 1 Storeroom Lock
Grade 1 Storeroom Lock, Athens Lever, Medeco LFIC Prep Less Core, Satin Chrome Finish, Non-Handed
Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
Proven, easy-to-install lever locks with extensive function, keying, trim and finish capabilities.
The Schlage® ND family significantly exceeds BHMA Grade 1 requirements for cycle, hammer blow, lever torque,lever pull and other tests. This means confidence that the lock will last, whether the application calls for high abuse resistance or just operation over millions of cycles—without any degradation in performance.
- Handing:All ND-Series lever locksets are non-handed.
- Door Thickness:1 5/8” to 2 1/8” (41mm–54mm) standard including Vandlgard® functions. 1 3/4” – 2” for function ND85. See accessories for spacers required for 1 3/8” doors.
- Backset:2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5” (60 mm, 95 mm, 127 mm) optional.
- Faceplate:Brass, bronze or stainless steel. 1 1/8” x 2 1/4” (29 mm x 57mm) square corner, beveled.
- Lock Chassis:Zinc plated for corrosion resistance.
- Latch Bolt:Steel, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
- Exposed Trim:Levers: Pressure cast zinc, plated to match finish symbols.
- Roses: Brass, bronze or zinc.
- Strike:ANSI curved lip strike 1 1/4” x 4 7/8” x 1 3/16” lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 21.
- Cylinder & Keys:6-pin Everest 29 S123keyway standard with two patented nickel silver keys per lock.
- Keying Options:Interchangeable core and Primus high security cylinders. Master keying, grand master keying and construction keying.
- Warranty:Ten-year limited for all functions including Vandlgard.
Attributes
Manufacturer surcharge: 4.5%
Accessible: Yes
Ada Compliance: Yes
Ansi: ANSI A156.2 Series 4000, Grade 1
Ansi Function: F86 – Storeroom
Baa Qualified: Yes
Bolt Projection: 1/2 In.
Bore Hole Diameter: 2-1/8 In.
Box Depth Fraction: 9-1/2 In.
Box Height Fraction: 4-3/4 In.
Box Width Fraction: 8-1/4 In.
Commercial Residential: Commercial
Country of origin: Mexico
Cylinder Type: Medeco LFIC Prep Less Core
Cylinders Present: Single Cylinder
Door Thickness: 1-5/8 In. to 2-1/8 In.
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 80-Storeroom Lock
Function Family: Storeroom
Grade: Grade 1
Handing: Non-handed
Installation: Commercial
Latch Bore Diameter: 1 In.
Lever Knob: Lever
Lever Knob Design Name: Athens
Leverknob Design: ATH – Athens Lever
Leverknob Design Family: Curved Lever
Limited Warranty: 10 Years
Lock Face Size: 1-1/8 In. x 2-1/4 In.
Manufacturer Function: Storeroom Lock
Maximum Door Thickness: 2-1/8 In.
Minimum Door Thickness: 1-5/8 In.
Origin: Mexico
Pack Height: 4.75″
Pack Height 2: 10″
Pack Length: 9.5″
Pack Length 2: 16.38″
Pack Qty: 1
Pack Volume: 372.28 in³
Pack Volume 2: 2394.84 in³
Pack Width: 8.25″
Pack Width 2: 14.63″
Pbs Options: ‘220317270,4541421
Pins: 6
Product Height: 3.44″
Product Length: 6.28″
Product Width: 3.31″
Projection: 3-5/16 In.
Rose Escutcheon: Rose
Roseescutcheon Design: 3-7/16″ Rose Diameter
Roseescutcheon Dimensions: 3-7/16″
Screws: Wood/Machine Screws
Series: ND Series Lever Locks
Ship Weight: 5 lbs.
Std Latch Backset Dim: 2-3/4 In.
Std Latch Number: 13-247
Std Latch Type: Deadlatch
Std Strike Height: 4-7/8 In.
Std Strike Number: 10-025
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4 In.
Strike Dimensions: 1-1/4 In. x 4-7/8 In.
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL/cUL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
Resources
- Everest 29 S Keyway Family Diagram
- Everest Keyways Diagram
- ND Series Electrified Functions Installation Instructions
- ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)
- ND Series Hollow Metal Door Spacer Installation Instructions
- ND Series Lever Locks Cut Sheet
- ND Series Locks & Latches Catalog
- ND Series Locks & Latches Warranty
- ND Series Mechanical Grade 1 Cylindrical Locks Catalog
- ND Series Template
- ND170 Installation Instructions (locks manufactured after 8-15-2012)
- ND170 Installation Instructions (locks manufactured before 8-15-2012)
- ND25 Installation Instructions (locks manufactured after 8-15-2012)
- ND25 Installation Instructions (locks manufactured before 8-15-2012)
- Observe Keyways for Classic Conventional Cylinders Diagram
- Observe Keyways for Classic Primus XP Cylinders Diagram
- Schlage ND Series Electrified Cylindrical Locks Sell Sheet
- Schlage ND Series Indicator Pricing Addendum
- Schlage ND Series Sell Sheet
- Schlage ND Series Service Manual
- Schlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)
- Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)
- Video: AL Lock Installation
- Von Duprin Finishes Chart
