Sargent 60-8204 LNE 3 Grade 1 Storeroom Lock, No DB Instructions
Sargent 60-8204 LNE 3 Grade 1 Storeroom Lock offers unparalleled strength and durability, making it an ideal choice for storeroom or closet applications. Exceeding ANSI/BHMA A156.13 Series 1000 Grade 1 standards, this mortise lock is engineered to provide maximum security and performance. Its construction features high-quality brass materials that ensure longevity and reliability. This robust lock is equipped with an E Lever design and is prepared for a Sargent LFIC Less Core, making it adaptable for various security key systems. The lock’s UL-cUL listing for three-hour fire doors adds an extra layer of safety in critical environments. With a variety of lever designs, escutcheon styles, and finishes available, the Sargent 60-8204 can seamlessly integrate into diverse architectural aesthetics, from offices to healthcare facilities. The lock’s ease of installation and maintenance, combined with a patented design, allows for simplified function changes without excessive inventory. With a 10-year limited warranty backing its quality, this mortise lock is the industry benchmark for performance and reliability. Choose the Sargent 60-8204 for a secure, stylish, and dependable locking solution that meets the demands of any application.
Grade 1 Storeroom, No DB
Storeroom or Closet Mortise Lock, LN Rose, E Lever, LFIC Prep Less Core, Bright Brass
When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
Constructed with the highest quality components to provide maximum security, durability and performance.
Considered the industry benchmark for all mortise locks on the market today, the robust lock is an attractive solution with a multitude of lever and escutcheon styles available.
Features:
- ANSI/BHMA Grade 2 certified for cycle and strength requirements
- UL-cUL listed for three-hour fire doors and windstorm applications
- Thru-bolted lever trim and strengthened cylinder retainer
- Available with security key systems (Degree, Signature, KESO, and XC)
- Available in 58 different functions, including electromechanical, security (freewheeling, security escutcheon, anti-vandal pull trim) and monitoring
- 6 lever designs, 2 roses/escutcheons designs, and 14 architectural finishes offered
- Available with behavioral health trim
- 10-year warranty
- Patented design and construction
Benefits:
- Strength & Reliability: Exceeds independent testing, making it the most durable mortise lock in the industry.
- Security: Security features provide resistance against unauthorized entry and vandalism.
- Flexibility & Aesthetics: Visual designwith a variety of functions, lever designs and architectural finishes match a wide range of styles and make it perfect for all types of applications (such as offices, hospitals, behavioral health environments, schools/universities).
- Ease of Installation & Maintenance: Multifunctional lockbody makes switching functions easy and reduces inventory requirements.
Attributes
Ansi Function: F07 – Storeroom/Exit
Application: Complete Lock
Baa Qualified: Yes
Base Material: Brass
Bolt Projection: 3/4″ Latch
Country of origin: USA
Cylinder Type: Sargent LFIC Less Core
Door Thickness: 1-3/4″
Finish: 605/US3
Fire Rated: 2 Hours {B}
Fire Rating: 2 Hours {B}
Function: 04-Storeroom or Closet
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: E – Lever
Limited Warranty: 10 Years
Lock Face Size: 8″ x 1-1/4″
Origin: USA
Pack Height: 4.38″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 227.64 in³
Pack Width: 5.63″
Roseescutcheon Design: LN – Rose
Screws: Combination
Series: 8200 Line Lever Mortise Locks
Ship Weight: 6.1 lbs.
Std Strike Height: 4-7/8″
Std Strike Number: 82-0110
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Locks Installation Instructions
- 7900/8200 Series Mortise Locks Installation Instructions
- 8200 Line Lever Mortise Locks Cut Sheet
- 8200 Mortise Sectional Indicator Trim Template
- Sargent 8200 Series Environmental Product Declaration (EPD)
- Sargent 8200 Series Mortise Locks Sell Sheet
- Video: 8200 Series Mortise Lock Installation
