Grade 1 Storeroom Deadbolt Lock by Schlage

Description

Schlage L9480L 02N 626 Lock Mortise Lock

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.

• Storeroom Lock with Deadbolt, Latchbolt Retracted By Key or Lever, Outside Always Fixed, Deadbolt Thrown By Key or Thumbturn, Turning Inside Lever Retracts Both Dead and Latchbolt, Auxiliary Latch Deadlocks Latchbolt When Locked, Inside Lever Always Free
• ANSI/BHMI Certified A156.13-2012
• Commercial Grade 1
• Lock Body Mortises Inside the Edge of the Door
• UL Listed for 3 Hour Fide Door

Attributes

Manufacturer surcharge: 4.5%

Baa Qualified: Yes

Base Material: Brass or Bronze

Bolt Projection: 3/4″ Latch, 1″ Deadbolt

Bolt Protection: 3/4″ Latch, 1″ Deadbolt

Commercial Residential: Commercial

Country of Origin: Mexico

Country of origin: Mexico

Cylinder Type: Less Cylinder

Door Thickness: 1-3/4″

Dust Box: Plastic

Finish: 626/US26D

Finish : Satin Chrome

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 9480-Storeroom Lock w Deadbolt

Grade: Grade 1

Hand: Field Reversible

Handing: Field Reversible

Installation: Commercial

Lever Knob Design: 02 – Lever

Leverknob Design: 02 Lever

Limited Warranty: 3 Years

Lock Face Size: 8″ x 1-1/4″

Origin: Mexico

Pack Height: 5.63″

Pack Height 2: 5.63″

Pack Length: 10.38″

Pack Length 2: 10.38″

Pack Qty: 1

Pack Volume: 313.68 in³

Pack Volume 2: 313.68 in³

Pack Width: 5.38″

Pack Width 2: 5.38″

Rose Escutcheon Design: N – Escutcheon

Roseescutcheon Design: N Escutcheon

Screws: Combination

Series: L9000 Series Mortise Lock

Ship Weight: 6.3 lbs.

Std Strike Height: 4-7/8″

Std Strike Number: 10-072

Std Strike Type: ASA

Std Strike Width: 1-1/4″

Strike: 10-072 Strike

Strike Height: 4-7/8″

Strike Number: 10-072

Strike Type: ASA

Strike Width: 1-1/4″

Subtype: Mortise Lock

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 6
