Description
Sargent 70-8206 LNL 32D Grade 1 Service Lock with No DB Instructions
Sargent 70-8206 LNL 32D Grade 1 Service Lock, No DB offers an unparalleled combination of strength, reliability, and versatility, making it an ideal choice for storeroom and service applications. This mortise lock is designed with a satin stainless steel finish and features the LN rose and L lever, enhancing both its function and aesthetic appeal. Exceeding ANSI/BHMA A156.13 Series 1000 Grade 1 standards, the Sargent 70-8206 is recognized as the benchmark for durability in the industry. Its construction includes high-quality components that ensure maximum security and performance, making it resistant to unauthorized entry and vandalism. The UL-cUL listing for three-hour fire doors and windstorm applications further underscores its reliability. With a field-reversible handing, the lock accommodates various door thicknesses (1-3/4″) and is compatible with SFIC prep less core cylinders. The lock boasts a 10-year warranty, emphasizing Sargent’s commitment to quality. Additionally, it offers a wide range of lever designs, escutcheon styles, and architectural finishes, providing flexibility to match diverse building aesthetics. Ideal for offices, hospitals, schools, and more, the Sargent 70-8206 is the reliable choice for professionals seeking a robust and attractive locking solution.
Grade 1 Service Lock, No DB
Storeroom or Service Mortise Lock, LN Rose, L Lever, SFIC Prep Less Core, Satin Stainless Steel
When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
Constructed with the highest quality components to provide maximum security, durability and performance.
Considered the industry benchmark for all mortise locks on the market today, the robust lock is an attractive solution with a multitude of lever and escutcheon styles available.
Features:
- ANSI/BHMA Grade 2 certified for cycle and strength requirements
- UL-cUL listed for three-hour fire doors and windstorm applications
- Thru-bolted lever trim and strengthened cylinder retainer
- Available with security key systems (Degree, Signature, KESO, and XC)
- Available in 58 different functions, including electromechanical, security (freewheeling, security escutcheon, anti-vandal pull trim) and monitoring
- 6 lever designs, 2 roses/escutcheons designs, and 14 architectural finishes offered
- Available with behavioral health trim
- 10-year warranty
- Patented design and construction
Benefits:
- Strength & Reliability: Exceeds independent testing, making it the most durable mortise lock in the industry.
- Security: Security features provide resistance against unauthorized entry and vandalism.
- Flexibility & Aesthetics: Visual designwith a variety of functions, lever designs and architectural finishes match a wide range of styles and make it perfect for all types of applications (such as offices, hospitals, behavioral health environments, schools/universities).
- Ease of Installation & Maintenance: Multifunctional lockbody makes switching functions easy and reduces inventory requirements.
Attributes
Application: Complete Lock
Baa Qualified: Yes
Base Material: Stainless Steel
Bolt Projection: 3/4″ Latch
Country of origin: USA
Cylinder Type: SFIC Prep Less Core
Door Thickness: 1-3/4″
Finish: 630/US32D
Fire Rated: 2 Hours {B}
Fire Rating: 2 Hours {B}
Function: 06-Storeroom or Service
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: L – Lever
Limited Warranty: 10 Years
Lock Face Size: 8″ x 1-1/4″
Origin: USA
Pack Height: 4.38″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 227.64 in³
Pack Width: 5.63″
Roseescutcheon Design: LN – Rose
Screws: Combination
Series: 8200 Line Lever Mortise Locks
Ship Weight: 6.1 lbs.
Std Strike Height: 4-7/8″
Std Strike Number: 82-0110
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Locks Installation Instructions
- 7900/8200 Series Mortise Locks Installation Instructions
- 8200 Line Lever Mortise Locks Cut Sheet
- 8200 Mortise Sectional Indicator Trim Template
- Sargent 8200 Series Environmental Product Declaration (EPD)
- Sargent 8200 Series Mortise Locks Sell Sheet
- Video: 8200 Series Mortise Lock Installation
