Grade 1 Narrow Rim Exit 710 – Von Duprin Delayed Egress Exit Device

Description

Von Duprin CXA33AEO 4 313 Grade 1 Narrow Rim Exit Device 710

Von Duprin CXA33AEO 4 313 Grade 1 Narrow Rim Exit 710 is a top-tier delayed egress exit device designed for commercial applications. This Grade 1 exit device features a narrow stile pushpad, measuring 48 inches, and operates as an exit-only mechanism. Built from durable dark bronze anodized aluminum, it combines both style and resilience, ensuring it complements various architectural aesthetics. The CXA33AEO is engineered for both single and double doors, offering a non-handed design for versatile installation. Its deadlocking latchbolt enhances security by preventing forced retraction, making it UL listed for panic exit hardware. The hex key dogging feature adds convenience, allowing for easy locking and unlocking. With motorized latch retraction options available, this device is suitable for modern access control systems. Designed to accommodate door sizes ranging from 34″ to 48″, it is compatible with metal or wood doors, ensuring broad usability. The CXA33AEO supports various electric options, including monitor switches and alarm exit kits, catering to your specific security needs. With a three-year limited warranty, this reliable exit device promises peace of mind for high-traffic environments. Choose Von Duprin for a secure, efficient, and stylish exit solution.

Grade 1 Narrow Rim Exit 710

Grade 1 Delayed Egress Exit Device, Narrow Stile Pushpad, 48″, Exit Only, Less Trim, Hex Key Dogging, Motorized Latch Retraction, Dark Bronze Anodized Aluminum Finish, Non-Handed

33A and 35A for all types of single and double doors with mullion, UL listed for panic exit hardware. Devices are ANSI A156.3 ñ 2014 Grade 1. The 35A has a smooth mechanism case and the 33A has grooved case. The rim device is non-handed except when the SS (signal switch) option is used. See opposite page for available outside trim and device functions.

The 33A Series features a grooved mechanism case and is for all types of single and double doors.

The 33A Series is UL listed for Panic Exit Device Hardware and has a deadlocking latchbolt that prevents forced latchbolt retraction providing higher security for your openings.

• Device Lengths:3’ 2’4″ to 3’ (711mm to 914 mm) door size; 4’ 2’10″ to 4’ (864 mm to 1219 mm) door size
• Strikes:1439 – Dull Black
• Dogging Feature:Hex key dogging standard
• Dogging Options:CD Cylinder Dogging; LD Less Dogging
• Electric Options:LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; SS Signal Switch; EL Electric Latch Retraction; ALK Alarm Exit Kit
• Miscellaneous Options:PN Pneumatic Latch Retraction; GBK Glass Bead Kit
• Fasteners & IncludesSex Bolts (SNB):1 3/4″ (44mm) – 2 1/4″ (57mm) Wood & Metal Doors; #425 SNB furnished standard for end case; #325 SNB furnished standard for EO (exit only device)
• Latch Bolt:Deadlocking, 3/4″ (19mm) throw
• Device Centerline from Finished Floor:39 13/16″ (1011 mm); 39 11/16″ (1008 mm) with Mullion
• Center Case Dimensions:8 3/16″ x 2 13/32″ x 1 9/16″ (208mm x 62mm x 40mm)
• Mechanism Case Dimensions:2 1/4″ x 2 1/4″ (57mm x 57mm)
• Projection:Pushbar Neutral – 3 13/16″ (97 mm); Pushbar Depressed – 3 1/16″ (78 mm)

Attributes

Manufacturer surcharge: 4.5%

Ansi: A156.3 2014

Base Material: Aluminum

Commercial Residential: Commercial

Device Length: 48″

Device Type: Rim

Dogging Options: Hex Key Dogging

Door Material: Metal or Wood

Door Thickness: 1-3/4″ to 2-1/4″

Door Width: 34″ to 48″

Electric Options: Motorized Latch Retraction

Finish: 313

Finish Family: Dark Bronze

Fire Rated: No

Grade: Grade 1

Handing: Non-Handed

Includes Trim: No

Installation: Commercial

Limited Warranty: 3 Years

Mechanical Function: Exit Only

Minimum Stile Size: Narrow

Pack Qty: 1

Physical Appearance: Narrow Stile Pushpad

Reversible: Yes

Series: 33A Series Rim Exit Device

Strike Standard: 1439

Subtype: Delayed Egress Exit Devices

Trim Type: Less Trim

Type: Exit Devices

Ul Listing: UL Listed

Unit of Measure: EACH

Unit of Measure 2: CASE

Unit of Measure 2 Qty: 3
