Grade 1 Narrow CVR Exit Device by PHI – Durable & Reliable

Description

PHI 2603 628 36 Grade 1 Narrow CVR Exit Device Instructions

PHI 2603 628 36 Grade 1 Narrow CVR Exit Device offers a reliable and aesthetically pleasing solution for various metal door applications. This Grade 1 concealed vertical rod exit device features a narrow stile pushpad design, making it ideal for both single and double door installations. With a storeroom function and hex key dogging, it ensures secure access control while complying with UL listed standards for panic and fire exit hardware. Engineered to accommodate door thicknesses from 1-3/4″ to 2-1/4″, the device fits openings up to 4′-0″ wide by 10′-0″ high, ensuring versatility across various settings. The satin aluminum clear anodized finish not only enhances durability but also provides a sleek, modern look.The PHI 2603 is designed with a 39-15/16″ touchbar height as standard, and it can be specified for different heights if needed. It features a robust lock stile assembly made from investment cast steel, complemented by stainless steel components for enhanced strength.Field reversible for easy installation, this exit device is certified to ANSI A156.3 Grade 1, ensuring it meets high-performance standards. Ideal for commercial settings, the PHI 2603 combines functionality with a refined design, making it a preferred choice among professionals in the industry.

Grade 1 Narrow CVR Exit Device

Grade 1 Concealed Vertical Rod Exit Device, Narrow Stile Pushpad, 36″ Device, Storeroom Function, Hex Key Dogging, Satin Aluminum Clear Anodized Finish, Field Reversible

The Apex 2000 Series Touchbar Style Exit Device is highly regarded by architects and end-users alike. Many of the nation’s largest healthcare and educational facilities prefer the Apex for its aesthetic design and efficient engineering. All Apex 2000 Series Exit Devices are UL listed for panic and fire hardware and are certified to ANSI A156.3 Grade 1.

For all types of metal single and double door applications.

Available for 1-3/4″ to 2-1/4″ thick, up to 4′-0″ wide by 10′-0″ high openings. For thicker doors, consult factory. Furnished standard for 1-3/4″ thick, 3′-0″ wide by 6′-8″ to 8′-0″ high openings.

• FUNCTIONS – A Universal Exit Device. Add Trim for desired function.
• BASE MATERIAL – Side Filler and End Cap are furnished of heavy wrought Brass, Bronze or Stainless Steel. 628 Devices are furnished with Aluminum, Brass, Bronze and Stainless Steel components.
• CHASSIS – Lock Stile Assembly – Investment Cast Steel, Zinc Dich-romated.
• TOP LATCHBOLT – Stainless Steel, Deadlocking, 3/4″ throw.
• TOP STRIKE – No. S519 Surface applied, Investment Cast Stainless Steel, Black Powder Coated.
• BOTTOM STRIKE – No. S460, Flush mounted, Steel, Black Powder Coated.
• DOGGING – 1/4″ turn hex key dogging standard. NOT available on Fire Exit Hardware.
• TOUCHBAR HEIGHT – 39-15/16″ from floor standard. Specify required height if other than standard.
• UL LISTED – Panic and Fire Exit Hardware. Conforms to UL10C and UBC 7-2.
• ANSI/BHMA – Devices are BHMA certified for ANSI 156.3, Grade 1.
• FINISHES – 605, 626, 612, 613, 625, 628, 630.
• CYLINDERS – Rim Type for “03” function, 1-1/4″ Long Mortise Type for “08” function. Cylinders are not furnished standard. Specify when required.

Attributes

Manufacturer surcharge: 7.0%

Ansi: A156.3

Baa Qualified: Yes

Base Material: Aluminum

Commercial Residential: Commercial

Country of origin: USA

Cylinder Type: Rim

Device Length: 36″

Device Type: Concealed Vertical Rod

Dogging Options: Hex Key Dogging

Door Material: Metal

Door Thickness: 1-3/4″

Door Width: 3′

Finish: 628/US28

Finish Family: Matte Silver

Fire Rated: No

Grade: Grade 1

Handing: Field Reversible

Includes Trim: No

Installation: Commercial

Limited Warranty: 5 Years

Mechanical Function: Storeroom

Origin: USA

Pack Qty: 1

Physical Appearance: Narrow Stile Pushpad

Reversible: Yes

Series: 2600 Series Apex Narrow Stile Concealed Vertical Rod Exit Devices

Strike Bottom: S460

Subtype: Concealed Vertical Rod Exit Devices

Top Strike: S519

Type: Exit Devices

Ul Listing: UL10C

Unit of Measure: Each
