Grade 1 Mts Exit Device 711 by Von Duprin – Durable Motorized Exit Solution

Description

Von Duprin QEL9875L-NL-06 4 315 RHR Grade 1 MTS Exit Device 711

Von Duprin QEL9875L-NL-06 4 315 RHR Grade 1 Motorized Exit Device offers an exceptional blend of security and convenience for both commercial and residential applications. Designed for single or double doors, this Grade 1 exit device features a wide stile pushpad and a quiet electric latch retraction mechanism, ensuring smooth, reliable operation. With a sturdy black anodized aluminum finish, this device is not only aesthetically pleasing but also durable, making it suitable for high-traffic areas. The device measures 48 inches in length and is compatible with stock hollow metal doors featuring an 86 cutout and stiles as narrow as 4-3/4 inches. The 7500 mortise lock is equipped with a field-reversible anti-friction latch bolt and a non-handed auxiliary bolt, providing enhanced deadlocking capabilities. This exit device meets UL listing standards for panic exit hardware and adheres to ANSI A156.3 – 2008 Grade 1 specifications, ensuring superior performance and safety. Installation is straightforward, with included fasteners suitable for 1-3/4″ to 2-1/4″ thick doors. The Von Duprin QEL9875L-NL-06 is an ideal choice for professionals seeking a reliable, efficient exit solution.

Grade 1 Mts Exit Device 711

Grade 1 Motorized Exit Device, Wide Stile Pushpad, 48″, Night Latch, Lever with Escutcheon, Less Dogging, Quiet Electric Latch Retraction, Black Anodized Aluminum Finish, Right Hand Reverse

9875/9975 Mortise lock device for all types of single or double doors, UL listed for panic exithardware. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4 3⁄4″ (121mm). The 7500 Mortise lock is equipped with a 3⁄4″ (19mm) anti-friction latch bolt which is fieldreversible without removing the lock from the door. It has a non-handed auxiliary bolt fordeadlocking and a faceplate with an adjustable bevel.

Fire exit mortise lock devices with a smooth mechanism case.

The 9875 Series is for all types of single or double doors and is UL listed for panic exit hardware. Devices are ANSI A156.3 – 2008 Grade 1. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4-3/4″ (121mm).

• Device Functions:Device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
• Device Lengths:
  • 3′ –2′ 4″to 3′ (711 mm to 914 mm) door size
  • 4′ –2′ 10″ to 4′ (864 mm to 1219 mm) door size
• Device centerline from finished door:
  • 39-13/16″ (1011 mm)
  • 39-11/16″ (1008 mm) with mullion
• Center case dimensions:8″ x 2-3/4″ x 2-3/8″ (203 mm x 70 mm x 60 mm)
• Mechanism case dimensions:2 1/4″ x 2 1/4″ (57 mm x 57 mm)
• Projection:Pushbar neutral – 3-13/16″ (97 mm); Pushbar depressed – 3-1/16″ (78 mm)
• Fasteners & sex bolts (SNB):Includes screw pack for 1-3/4″ (44 mm) and 2-1/4″ (57 mm) thick metal or wood doors.

Attributes

Manufacturer surcharge: 4.5%

Accessible: No

Ada Compliance: No

Ansi: A156.3 2014

Baa Qualified: Yes

Burglar Rated: No

Commercial Residential: Commercial

Country of origin: USA

Design A: 06 Lever

Device Length: 48″

Device Type: Mortise

Dogging Options: Less Dogging

Door Material: Wood or Metal

Door Thickness: 1-3/4″ to 2-1/4″

Door Width: 34″ to 48″

Electric Options: Motorized Latch Retraction

Finish: 315/335

Finish Family: Black

Fire Rated: No

Fire Rating: No

Grade: Grade 1

Handing: Right Hand Reverse

Includes Cylinders: No

Includes Trim: Yes

Installation: Commercial

Limited Warranty: 1 Year

Mechanical Function: Night Latch

Minimum Stile Size: 4-3/4″

Origin: USA

Pack Height: 10.5″

Pack Height 2: 11.75″

Pack Length: 49″

Pack Length 2: 50″

Pack Qty: 1

Pack Volume: 2572.5 in³

Pack Volume 2: 9400 in³

Pack Width: 5″

Pack Width 2: 16″

Physical Appearance: Wide Stile Pushpad

Product Height: 8″

Product Length: 45″

Product Width: 3.75″

Restrictions: None

Reversible: Yes

Series: 9875 Series Mortise Exit Device

Ship Weight: 23 lbs.

Strike Standard: 575

Subtype: Motorized Exit Devices

Trim Design: Lever with Escutcheon

Trim Part No: 996L-NL-06-M US19 RHR

Trim Type: Lever

Type: Exit Devices

Ul Listing: UL 305

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 3
