Grade 1 Mts Exit Device 630 by Von Duprin – Reliable Mortise Exit Solution

Description

Von Duprin LD9875EO 4 32D Grade 1 MTS Exit Device 630

Von Duprin LD9875EO 4 32D Grade 1 Mts Exit Device 630 is a robust solution for ensuring safe egress in commercial settings. This Grade 1 mortise exit device features a wide stile pushpad and measures 48 inches long, designed specifically for exit-only applications. Crafted from satin stainless steel, it boasts a sleek finish that complements various door styles while ensuring durability. Engineered to fit stock hollow metal doors with an 86 cutout, the LD9875EO accommodates door stiles as narrow as 4-3/4 inches. Its advanced design includes a 3/4-inch anti-friction latch bolt, allowing for field reversibility without the need to remove the lock from the door. The device is equipped with a non-handed auxiliary bolt for deadlocking, enhancing security. The LD9875 series is UL listed for panic exit hardware, ensuring compliance with safety regulations. With ANSI A156.3-2008 Grade 1 certification, this exit device is ideal for both single and double doors, making it a versatile choice for various applications. Installation is straightforward, with included fasteners for 1-3/4 inch to 2-1/4 inch thick doors. With a 3-year limited warranty, the Von Duprin LD9875EO is a reliable addition to any commercial space, combining functionality and style seamlessly.

Grade 1 Mts Exit Device 630

Grade 1 Mortise Exit Device, Wide Stile Pushpad, 48″, Exit Only, Less Trim, Less Dogging, Satin Stainless Steel Finish, Non-Handed

9875/9975 Mortise lock device for all types of single or double doors, UL listed for panic exithardware. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4 3⁄4″ (121mm). The 7500 Mortise lock is equipped with a 3⁄4″ (19mm) anti-friction latch bolt which is fieldreversible without removing the lock from the door. It has a non-handed auxiliary bolt fordeadlocking and a faceplate with an adjustable bevel.

Fire exit mortise lock devices with a smooth mechanism case.

The 9875 Series is for all types of single or double doors and is UL listed for panic exit hardware. Devices are ANSI A156.3 – 2008 Grade 1. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4-3/4″ (121mm).

• Device Functions:Device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
• Device Lengths:
  • 3′ –2′ 4″to 3′ (711 mm to 914 mm) door size
  • 4′ –2′ 10″ to 4′ (864 mm to 1219 mm) door size
• Device centerline from finished door:
  • 39-13/16″ (1011 mm)
  • 39-11/16″ (1008 mm) with mullion
• Center case dimensions:8″ x 2-3/4″ x 2-3/8″ (203 mm x 70 mm x 60 mm)
• Mechanism case dimensions:2 1/4″ x 2 1/4″ (57 mm x 57 mm)
• Projection:Pushbar neutral – 3-13/16″ (97 mm); Pushbar depressed – 3-1/16″ (78 mm)
• Fasteners & sex bolts (SNB):Includes screw pack for 1-3/4″ (44 mm) and 2-1/4″ (57 mm) thick metal or wood doors.

Attributes

Manufacturer surcharge: 4.5%

Accessible: No

Ada Compliance: No

Ansi: A156.3 2014

Baa Qualified: Yes

Burglar Rated: No

Commercial Residential: Commercial

Country of origin: USA

Device Length: 48″

Device Type: Mortise

Dogging Options: Less Dogging

Door Material: Wood or Metal

Door Thickness: 1-3/4″ – 2-1/4″

Door Width: 34″ to 48″

Finish: 630/US32D

Finish Family: Matte Silver

Fire Rated: No

Fire Rating: No

Grade: Grade 1

Handing: Non-Handed

Includes Cylinders: No

Includes Trim: No

Installation: Commercial

Limited Warranty: 3 Years

Mechanical Function: Exit Only

Minimum Stile Size: 4-3/4″

Origin: USA

Pack Height: 10.5″

Pack Height 2: 11.75″

Pack Length: 49″

Pack Length 2: 50″

Pack Qty: 1

Pack Volume: 2572.5 in³

Pack Volume 2: 9400 in³

Pack Width: 5″

Pack Width 2: 16″

Physical Appearance: Wide Stile Pushpad

Product Height: 8″

Product Length: 45″

Product Width: 3.75″

Restrictions: None

Reversible: Yes

Series: 9875 Series Mortise Exit Device

Ship Weight: 18 lbs.

Strike Standard: 575

Subtype: Mortise Exit Devices

Trim Part No: Less Trim

Trim Type: Less Trim

Type: Exit Devices

Ul Listing: UL 305

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 3
