Grade 1 Faculty RR wDeadbolt by Schlage – Secure Door Locking Solution

Description

Schlage L9486P 06A 625 LH Lock Mortise Lock

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.

Attributes

Manufacturer surcharge: 4.5%

Baa Qualified: Yes

Base Material: Brass or Bronze

Bolt Projection: 3/4″ Latch, 1″ Deadbolt

Bolt Protection: 3/4″ Latch, 1″ Deadbolt

Commercial Residential: Commercial

Country of Origin: Mexico

Country of origin: Mexico

Cylinder Type: Conventional Cylinder

Door Thickness: 1-3/4″

Dust Box: Plastic

Finish: 625/US26

Finish : Bright Chrome

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 9486-Faculty Restroom Lock w Indicator

Grade: Grade 1

Hand: LH

Handing: LH

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Keyway: S123

Lever Knob Design: 06 – Lever

Leverknob Design: 06 Lever

Limited Warranty: 3 Years

Lock Face Size: 8″ x 1-1/4″

Num Of Keys: 2

Num Pins: 6

Of Keys: 2

Origin: Mexico

Pack Height: 5.63″

Pack Height 2: 5.63″

Pack Length: 10.38″

Pack Length 2: 10.38″

Pack Qty: 1

Pack Volume: 313.68 in³

Pack Volume 2: 313.68 in³

Pack Width: 5.38″

Pack Width 2: 5.38″

Pins: 6

Rose Escutcheon Design: A – Rose

Roseescutcheon Design: A Rose

Screws: Combination

Series: L9000 Series Mortise Lock

Ship Weight: 6.3 lbs.

Std Keyway: S123

Std Strike Height: 4-7/8″

Std Strike Number: 10-072

Std Strike Type: ASA

Std Strike Width: 1-1/4″

Strike: 10-072 Strike

Strike Height: 4-7/8″

Strike Number: 10-072

Strike Type: ASA

Strike Width: 1-1/4″

Subtype: Mortise Lock

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 6

Resources

• L Series Mounting Plate Installation Instructions
• L400 Installation Instructions
• L9000 Indicator Handing Instructions
• L9000 Indicator Lever w/ Escutcheon Installation Instructions
• L9000 Indicator Lever w/ Sectional Installation Instructions
• L9000 Installation Instructions
• L9000 Knob Installation Instructions
• L9000 Series Mortise Lock Cut Sheet
• Schlage L Indicator Data Sheet
• Schlage L Series Parts Diagram
• Schlage L Series Service Manual
• Schlage L9000 Gen 2 Indicator Pricing Addendum
• Video: AL Lock Installation
• Von Duprin Finishes Chart
