Schlage LV9486P 07A 626 L583-375 RH Grade 1 Faculty RR Deadbolt
Schlage LV9486P 07A 626 L583-375 RH Grade 1 Faculty RR w/Deadbolt offers a robust and reliable locking solution specifically designed for high-traffic areas such as schools, hospitals, and factories. This faculty restroom mortise lock features the Vandlgard design, ensuring enhanced security and ease of use. Crafted from extra heavy-duty materials, the lock boasts a fully wrapped heavy-gauge steel case that protects against door edge attacks and wear. Meeting ANSI Grade 1 standards, the LV9486P combines durability with advanced built-in security features. Its break-away spindle prevents unsecured failures, while the spring-loaded fusible link ensures fail-secure operation during fire emergencies. The lock is adaptable, featuring a universal case that allows for ten functions in one. The floating mounting tabs accommodate beveled doors, and field-reversible handing can be achieved without opening the lock case. With a satin chrome finish and a sleek 07 lever design, this lock not only provides functionality but also enhances the aesthetic appeal of any environment. Standard keying options and a locking thumb-turn indicator offer added convenience. Trust Schlage’s L9000 Series for a dependable locking solution that meets both security and aesthetic needs.
Grade 1 Faculty RR wDeadbolt
Faculty Restroom Mortise Lock with Vandlgard, 07A Design,Satin Chrome
Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
Extra heavy duty mortise lock protected by all metal heavy-gauge steel.
Schlage L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse.
Durability and Strength
- Heavy-gauge, fully wrapped steel case protects against door edge attacks
- All-metal zinc dichromate-plated working parts
- Electronic components protected by inside lock case
- Wear and tear reduced by two-piece anti-friction tongue
- Outside and inside trim thru-bolted together and through the door
Built-in Security
- Unsecured failures prevented by break-away spindle, also providing easy spindle replacement
- Spindle manipulation discouraged by hub blocking plate
- Spring-loaded fusible link provides fail secure mode in case of fire
- Inside lever applied by screwless shank mounting – no exposed trim mount screws
Adaptable to your application
- Universal lock case featuring ten functions in one case
- Floating mounting tabs adjust to fit a beveled door edge
- Field-reversible handing without opening lock case
- Simple trim retrofit made possible by external spring cages
- Locking thumb-turn on the inside of door shows when the door is unlocked and locked
- Lever rotation in both directions for ease of use
- Independent lever rotation
Attributes
Manufacturer surcharge: 4.5%
Baa Qualified: Yes
Base Material: Brass or Bronze
Bolt Projection: 3/4″ Latch, 1″ Deadbolt
Commercial Residential: Commercial
Country of origin: Mexico
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/4″
Dust Box: Plastic
Finish: 626/US26D
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 9486-Faculty Restroom Lock w Indicator
Grade: Grade 1
Handing: RH
Installation: Commercial
Keying: Keyed Different
Keys: Cut
Leverknob Design: 07 Lever
Limited Warranty: 3 Years
Lock Face Size: 8″ x 1-1/4″
Of Keys: 2
Origin: Mexico
Pack Height: 5.63″
Pack Height 2: 5.63″
Pack Length: 10.38″
Pack Length 2: 10.38″
Pack Qty: 1
Pack Volume: 313.68 in³
Pack Volume 2: 313.68 in³
Pack Width: 5.38″
Pack Width 2: 5.38″
Pins: 6
Roseescutcheon Design: A Rose
Screws: Combination
Series: L9000 Series Mortise Lock
Ship Weight: 6.3 lbs.
Std Keyway: S123
Std Strike Height: 4-7/8″
Std Strike Number: 10-072
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
Resources
- L Series Mounting Plate Installation Instructions
- L400 Installation Instructions
- L9000 Indicator Handing Instructions
- L9000 Indicator Lever w/ Escutcheon Installation Instructions
- L9000 Indicator Lever w/ Sectional Installation Instructions
- L9000 Installation Instructions
- L9000 Knob Installation Instructions
- L9000 Series Mortise Lock Cut Sheet
- Schlage L Indicator Data Sheet
- Schlage L Series Parts Diagram
- Schlage L Series Service Manual
- Schlage L9000 Gen 2 Indicator Pricing Addendum
- Video: AL Lock Installation
- Von Duprin Finishes Chart
