Grade 1 Exit Lock by Schlage – Durable Door Hardware

Description

Schlage L902507B626 Exit Mortise Lock with 07 Lever and B Rose Satin Chrome Finish

Schlage Commercial L902507B626 Exit Mortise Lock with 07 Lever and B Rose Satin Chrome Finish

• Exit
• ANSI/BHMI Certified A156.13-2012
• Commercial Grade 1
• Lock Body Mortises Inside the Edge of the Door
• UL Listed for 3 Hour Fide Door

Attributes

Manufacturer surcharge: 4.5%

Ansi: A156.13-2017 Series 1000, Grade 1

Ansi Function: F31 – Exit

Baa Qualified: Yes

Bolt Projection: 3/4″ Latch

Commercial Residential: Commercial

Country of Origin: Mexico

Country of origin: Mexico

Design: 07 Lever and B Rose

Door Thickness: 1-3/4″

Finish: Satin Chrome

Finish : Satin Chrome

Finish Family: Matte Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 9025-Exit

Grade: Grade 1

Handing: Field Reversible

Installation: Commercial

Leverknob Design: 07 Lever

Leverknob Design Family: Curved Lever

Limited Warranty: 3 Years

Lock Face Size: 8″ x 1-1/4″

Origin: Mexico

Pack Height: 5.5″

Pack Length: 10.25″

Pack Qty: 1

Pack Volume: 295.97 in³

Pack Width: 5.25″

Projection: 2-7/8″

Roseescutcheon Design: B Rose

Roseescutcheon Dimensions: 2-9/16″

Series: L Series

Ship Weight: 6 lbs.

Std Latch Backset Dim: 2-3/4″

Std Latch Type: Dead Latch (Guarded)

Std Strike Height: 4-7/8″

Std Strike Number: 10-072 1316 626

Std Strike Type: ANSI Strike

Std Strike Width: 1-3/16″

Strike: 10-072 Strike

Subtype: Mortise

Type: Mechanical Commercial Locksets

Ul Listing: UL Listed

Unit of Measure: Each

Resources

• L Series Mounting Plate Installation Instructions
• L400 Installation Instructions
• L9000 Indicator Handing Instructions
• L9000 Indicator Lever w/ Escutcheon Installation Instructions
• L9000 Indicator Lever w/ Sectional Installation Instructions
• L9000 Installation Instructions
• L9000 Knob Installation Instructions
• L9000 Series Mortise Lock Cut Sheet
• Schlage L Indicator Data Sheet
• Schlage L Series Parts Diagram
• Schlage L Series Service Manual
• Schlage L9000 Gen 2 Indicator Pricing Addendum
• Video: AL Lock Installation
• Von Duprin Finishes Chart
