Grade 1 CVR Exit Device by Yale – Reliable Safety Solution

Description

Yale 6160ED 36-7 629 Grade 1 CVR Exit Device Instructions

Yale 6160ED 36-7 629 Grade 1 CVR Exit Device offers a reliable and stylish solution for commercial exit needs. This Grade 1 concealed vertical rod exit bar is designed for doors ranging from 30″ to 36″ wide and up to 7′ tall, making it suitable for a variety of applications, including multi-family residences, retail spaces, and office buildings. Crafted with a bright stainless steel finish, this exit device not only ensures enduring performance but also enhances the aesthetic of your entryway. The Yale 6160ED features a wide stile pushpad for easy operation, and its hex key dogging mechanism adds convenience when securing the exit. It is non-handed, allowing for versatile installation on both left and right-handed doors. The durable aluminum rail design, complemented by an architecturally finished touch bar, minimizes damage and catch points, ensuring longevity even in high-traffic environments. With ANSI/BHMA A156.3 Grade 1 certification, you can trust the Yale 6160ED for superior performance. It is available in various mechanical and electromechanical functions, allowing for customized solutions to meet specific security needs. Backed by a 10-year limited warranty, this exit device is a smart investment for any commercial facility seeking reliability and style.

Grade 1 CVR Exit Device

Grade 1 Concealed Vertical Rod Exit Bar Over 8′, Wood Door or LBR, Wide Stile Pushpad, Hex Key Dogging, 30″ – 36″ Door Opening Width, 7′ Door Height, Less Trim, Bright Stainless Steel Finish, Non-Handed

With its robust, modern design and smooth, quiet operation, the Yale 6000 Series exit device provides an attractive solution that can withstand the rigors of multi-family, retail, office and other commercial exits. The stylish, clean lines of the wide and narrow stile 6000 exit device are visually appealing and blend with any decor. With a range of mechanical and electromechanical functions available, the 6000 can be used in many types of commercial facilities, including office buildings, retail environments, and mixed-use facilities.

Robust, modern design and smooth, quiet operation – for multi-family, retail, office and commercial exits.

The stylish, clean lines of the wide and narrow stile 6000 exit device are visually appealing and blend with any décor. With a range of mechanical and electromechanical functions available, the 6000 can be used in many types of commercial facilities, including office buildings, retail environments, and mixed-use facilities.The stylish, clean lines of the wide and narrow stile 6000 exit device are visually appealing and blend with any décor. With a range of mechanical and electromechanical functions available, the 6000 can be used in many types of commercial facilities, including office buildings, retail environments, and mixed-use facilities.

• ANSI/BHMA A156.3 Grade 1 Certified
• Available as rim, mortise, SquareBolt®, surface vertical rod and concealed vertical rod in wide or narrow stile configurations
• Highly durable aluminum rail design with architecturally finished touch bar in 5 finishes
• Heavy duty, angled end cap design protects rail, eliminates catch points and reduces damage
• Available in 13 mechanical functions and 11 electromechanical functions
• Available with standard or Reflections® decorative levers
• Complete offering of mechanical and electromechanical solutions
• Available with Microshield® antimicrobial coating
• Warranty: 10 years

Attributes

Ansi: ANSI/BHMA A156.3 Grade 1

Commercial Residential: Commercial

Device Length: 36″

Device Type: Concealed Vertical Rod

Dogging Options: Hex Key Dogging

Door Height: 7′

Door Material: Wood

Door Thickness: 1-3/4″

Door Width: 30″ – 36″

Finish: 629/US32

Finish Family: Polished Silver

Fire Rated: No

Fire Rating: No

Grade: Grade 1

Handing: Non-Handed

Includes Cylinders: No

Includes Trim: No

Installation: Commercial

Limited Warranty: 10 Years

Minimum Stile Size: 4-1/2″

Pack Qty: 1

Physical Appearance: Wide Stile Pushpad

Reversible: Yes

Series: Yale 6000 Series Exit Devices

Strike Bottom: 790

Subtype: Concealed Vertical Rod Exit Devices

Top Strike: 761

Type: Exit Devices

Unit of Measure: Each

Resources

• 2023 Yale Commercial Price Book (effective 4.17.2023)
• 6000 Series Exit Devices Catalog
• Yale 6000 Series Exit Devices Cut Sheet
• Yale Commercial Finishes Chart
