Description
Sargent 8226 EE BSP Gr1 Store Door with Deadbolt
Sargent 8226 EE BSP Gr1 Store Door w/Deadbolt offers unparalleled strength and durability, making it the gold standard in mortise locks. This Grade 1 store door mortise lock features an E-lever design and E-rose configuration, ensuring it meets and exceeds ANSI/BHMA A156.13 Series 1000 standards. Its robust construction incorporates high-quality components, providing maximum security and performance. Designed for versatility, the lock is field reversible and comes with a conventional cylinder and ASA strike. Its UL-cUL certification for three-hour fire doors and windstorm applications enhances its reliability in critical environments. With a variety of lever designs, architectural finishes, and 58 different functions-including electromechanical options-this lock seamlessly blends security with aesthetics, making it suitable for offices, hospitals, schools, and more. The patented design ensures ease of installation and maintenance, reducing inventory requirements with its multifunctional lock body. Additionally, the Sargent 8226 is backed by a 10-year warranty, assuring long-term reliability. Experience the strength, flexibility, and security of the Sargent 8226 EE BSP, the ideal choice for demanding applications where safety and performance are paramount.
Gr1 Store Door wDeadbolt
Grade 1 Store Door Mortise Lock, E – Lever, E – Rose, Field Reversible, Conventional Cylinder, ASA Strike, Black Suede Powder Coat
When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
Constructed with the highest quality components to provide maximum security, durability and performance.
Considered the industry benchmark for all mortise locks on the market today, the robust lock is an attractive solution with a multitude of lever and escutcheon styles available.
Features:
- ANSI/BHMA Grade 2 certified for cycle and strength requirements
- UL-cUL listed for three-hour fire doors and windstorm applications
- Thru-bolted lever trim and strengthened cylinder retainer
- Available with security key systems (Degree, Signature, KESO, and XC)
- Available in 58 different functions, including electromechanical, security (freewheeling, security escutcheon, anti-vandal pull trim) and monitoring
- 6 lever designs, 2 roses/escutcheons designs, and 14 architectural finishes offered
- Available with behavioral health trim
- 10-year warranty
- Patented design and construction
Benefits:
- Strength & Reliability: Exceeds independent testing, making it the most durable mortise lock in the industry.
- Security: Security features provide resistance against unauthorized entry and vandalism.
- Flexibility & Aesthetics: Visual designwith a variety of functions, lever designs and architectural finishes match a wide range of styles and make it perfect for all types of applications (such as offices, hospitals, behavioral health environments, schools/universities).
- Ease of Installation & Maintenance: Multifunctional lockbody makes switching functions easy and reduces inventory requirements.
Attributes
Ansi Function: F14 – Store Door
Baa Qualified: Yes
Bolt Projection: 3/4 In. Latch, 1 in. Deadbolt
Country of origin: USA
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/4 In.
Finish: BSP
Fire Rated: 2 Hours {B}
Fire Rating: 2 Hours {B}
Function: 26-Store Door
Grade: Grade 1
Handing: Field Reversible
Keying: Keyed Different
Keys: Cut
Leverknob Design: E – Lever
Limited Warranty: 10 Years
Lock Face Size: 8 In. x 1-1/4 In.
Of Keys: 2
Origin: USA
Pack Height: 4.38″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 227.64 in³
Pack Width: 5.63″
Pins: 6
Roseescutcheon Design: E – Rose
Screws: Combination
Series: 8200 Line Lever Mortise Locks
Ship Weight: 6.1 lbs.
Std Keyway: LA
Std Latch Backset Dim: 2-3/4 In.
Std Latch Type: Combination Latch and Bolt
Std Strike Height: 4-7/8 In.
Std Strike Type: ASA Strike
Std Strike Width: 1-1/4 In.
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructions
- 7800/8200 Series Mortise Locks Installation Instructions
- 7900/8200 Series Mortise Locks Installation Instructions
- 8200 Line Lever Mortise Locks Cut Sheet
- 8200 Mortise Sectional Indicator Trim Template
- Sargent 8200 Series Environmental Product Declaration (EPD)
- Sargent 8200 Series Mortise Locks Sell Sheet
- Video: 8200 Series Mortise Lock Installation
